Description
The HPE Aruba Networking CX 8360-48Y6C v2 is a high-performance, enterprise-grade Layer 3 switch designed for modern core and aggregation networks. With 48 ports of 1/10/25G SFP/SFP+/SFP28 and 6 high-speed 40/100G QSFP+/QSFP28 uplinks, it delivers up to 4.8 Tbps of switching capacity in a compact 1U form factor. Equipped with MACsec encryption on select ports, it provides secure connectivity across untrusted domains.
Powered by the AOS-CX operating system, it supports advanced automation, telemetry, and fault tolerance through microservices architecture and built-in Network Analytics Engine (NAE). Ideal for campus cores, data centers, and cloud-driven infrastructures, the 8360-48Y6C v2 switch supports redundant power and fans, and front-to-back airflow for reliable operation in mission-critical environments.
| Specification | Details |
|---|---|
| Model Number | JL704C#ABA |
| Switch Type | Layer 3 Managed |
| Ports | 44 x 1/10/25G SFP/SFP+/SFP284 x 10/25G SFP+/SFP28 with MACsec4 x 40/100G QSFP+/QSFP282 x 40/100G QSFP+/QSFP28 with MACsec |
| Switching Capacity | 4.8 Tbps |
| Forwarding Rate | 2,678 Mpps |
| MACsec Support | On 4 x 25G and 2 x 100G ports |
| Processor | 1.8 GHz 4-core 64-bit |
| Memory | 16 GB RAM, 32 GB Flash |
| Packet Buffer | 32 MB |
| Power Supplies | 2x Field-replaceable, hot-swappable AC |
| Power Consumption | 725W max / 230W idle |
| Heat Dissipation | 1,450 BTU/hr |
| Airflow | Front-to-back |
| Dimensions (WxDxH) | 17.4 x 22.0 x 1.73 in |
| Weight | 23.65 lb |
| Management Interfaces | RJ45 Console, USB-C, RJ45 Ethernet, USB-A |
| Routing Protocols Supported | Static, RIP/RIPng, OSPF/OSPFv3, BGP-4, MP-BGP (IPv6), PBR, ECMP, GRE, MPLS |
| Software Features | AOS-CX, Network Analytics Engine, VSX, REST APIs, Python Scripting, HPE Fabric Composer |
