Description
The HPE Aruba Networking 9004 (RW) LTE Branch Gateway is a compact, high-performance solution designed to unify SD-WAN, wired, and wireless networks for small campuses and branch offices. With integrated LTE for dedicated or redundant WAN uplink, it supports up to 2,000 clients and 32 access points, delivering secure, scalable connectivity in a fanless, desktop form factor.
Powered by Aruba’s SD-Branch architecture, it provides advanced security with a built-in Layer 4–7 policy enforcement firewall, role-based IDS/IPS, and application visibility into over 3,800 apps. Deployment is streamlined via mobile provisioning, while centralized management and orchestration are available through Aruba Central.
Whether you’re extending secure SD-WAN to remote sites or need LTE for failover, the Aruba 9004 LTE Gateway delivers reliability, flexibility, and enterprise-grade security.
| Feature | Details |
|---|---|
| Model | HPE Aruba Networking 9004 (RW) LTE Branch Gateway |
| SKU | R3V90A |
| Form Factor | Desktop, fanless |
| Ethernet Ports | 4x 10/100/1000BASE-T |
| LTE Support | Integrated LTE (Category 12), global coverage, 600/150 Mbps (DL/UL) |
| Max Clients | 2,000 |
| Max Access Points (APs) | 32 |
| Firewall Throughput | 4 Gbps |
| Max Datapath/Firewall Sessions | 128K |
| Encrypted Throughput (AES-128) | 4 Gbps |
| Max VLANs | 4K |
| Max DHCP Clients | 4,000 |
| Wi-Fi/IoT Radios | Bluetooth 5, Zigbee, NFC |
| USB Port | 1x USB 3.0 Type-A |
| Console Ports | Micro-USB and RJ45 |
| LTE Antenna Ports | 2x SMA (main/diversity), 1x SMA (GPS) |
| Dimensions (H x W x D) | 3.82 cm x 19.85 cm x 15.31 cm |
| Weight | 1.143 kg |
| Power Consumption | Max 25W (with USB) |
| Operating Temperature | 0°C to 40°C |
| Mounting Options | Optional 19-inch rack mount kit (R3W17A) |
| Management | Aruba Central (cloud-based), mobile app provisioning |
| Software Support | AOS 10.4+, SD-WAN R2.2.0.2+, Aruba Central 2.5.x |
