Description
The HPE Aruba Networking 9106 Hybrid Gateway is a high-performance, cloud-managed edge appliance purpose-built to deliver seamless enterprise services to large branch offices and small campus networks. Powered by ArubaOS 10.6 and managed through Aruba Central, this hybrid gateway provides reliable 24/7 Wi-Fi roaming, scalable performance, and AI-driven management for modern edge networking needs.
Supporting up to 4,000 APs and 10,000 clients, the 9106 Gateway ensures robust connectivity and resiliency with features like clustering, redundancy, and live upgrades. With advanced firewall and dynamic segmentation, it provides secure, role-based access for both users and IoT devices across LAN, WAN, and SD-WAN networks. Versatile deployment modes include SD-Branch Gateway, Cloud Wireless Gateway, and VPN Concentrator (VPNC).
Designed for easy installation in a 1U rack-mount form factor, this 6-port gateway supports high-speed 10GbE and 1GbE interfaces, PoE, and dynamic traffic segmentation—all optimized for enterprise-class wired and wireless performance.
| Specification | Details |
|---|---|
| Product Type | Hybrid Cloud-Managed Gateway |
| Model | HPE Aruba 9106 |
| Part Number | S0B85A#ABA |
| Form Factor | 1U Rack-Mountable, Desktop |
| Management | Cloud-Managed via Aruba Central, ArubaOS 10.6 |
| Connectivity | Wired |
| Ports | 2 x 10GbE SFP+, 2 x 1GbE RJ-45/SFP, 2 x 1GbE RJ-45 PoE, Console (RJ-45, USB-C), USB 3.0 |
| Max APs per Gateway / Cluster | 2,000 / 4,000 |
| Max Clients per Gateway / Cluster | 8,000 / 32,000 |
| Max Concurrent IPSec Tunnels | 16,000 |
| Max Throughput | 10 Gbps |
| Firewall / Sessions | L4-7 Stateful Firewall / 2 Million Sessions |
| Redundancy & Clustering | N+1 / NxN with hitless failover |
| Mounting | Rack mounting kit (2-post) included |
| Power Supply | External Power Adapter, 165W (150W operational) |
| PoE Support | Yes (60W via Ethernet ports) |
| OS Required | ArubaOS 10.6 |
| Compliance & Certifications | FCC, UL, CSA, VCCI, EN55032 Class A, etc. |
| Dimensions (W x D x H) | 1.7 in x 11.6 in x 7.9 in |
| Weight | 5.08 lbs (2.3 kg) |
| Environment | Operating Temp: 32–104°F, Humidity: 10–90% RH (non-condensing) |
| Warranty | 1-Year Limited Parts & Labor |
