Description
The HPE Aruba Networking AP-518 (EG) is a high-performance, dual-radio Wi-Fi 6 access point designed for harsh, weather-protected environments such as warehouses, stadium enclosures, and industrial zones. Featuring a ruggedized design and support for external antennas, the AP-518 ensures reliable and secure high-speed wireless connectivity even under extreme environmental conditions.
Supporting advanced technologies like 4x4 MU-MIMO, OFDMA, Bluetooth 5, Zigbee, WPA3 security, and HPE Aruba Networking’s AI-powered ClientMatch, this access point delivers exceptional performance for dense client environments and IoT deployments. With a maximum aggregate wireless throughput of up to 3 Gbps, integrated surge protection, and flexible power and management options, the AP-518 is engineered for resilience, security, and scalability.
| Specification | Details |
|---|---|
| SKU / Part Number | R4G99A |
| AP Type | Indoor Hardened, Dual-Radio, Wi-Fi 6 (802.11ax) |
| Radios & Antennas | 5 GHz: 4x RP-SMA connectors2.4 GHz: 2x RP-SMA connectors |
| MIMO Configuration | 5 GHz: 4x4 MIMO2.4 GHz: 2x2 MIMO |
| Maximum Data Rate | Up to 3 Gbps aggregate |
| Wi-Fi Features | OFDMA, MU-MIMO, Tx Beamforming, DFS, ClientMatch™, ACC |
| Wireless Standards | 802.11a/b/g/n/ac/ax |
| Security | WPA3, Enhanced Open, WPA2-MPSK, TPM, VPN Tunnel Support |
| IoT Radios | Bluetooth 5 and Zigbee (802.15.4) |
| Ports | 1x SmartRate 100/1000/2500BASE-T (PoE+)1x 10/100/1000BASE-TUSB-C Console |
| Power Options | 802.3at PoE+ (Class 4)Max consumption: 25.6W |
| Management | Aruba Central, AirWave, Mobility Controller, InstantOS |
| Max Client Devices | 512 per radio (1,024 total) |
| Mounting Options | AP-220-MNT-W1, AP-270 series with adapter |
| Environmental Rating | IP55, -40°C to +55°C operating temp |
| Certifications | CB Scheme, cTUVus, UL2043, Wi-Fi CERTIFIED 6, FCC, CE, EN60601 |
| Dimensions (H x W x D) | 75 x 220 x 220 mm (2.5 x 8.5 x 8.5 in) |
| Weight | 1.5 kg (3.3 lbs) |
| Warranty | Limited Lifetime Warranty |
