Description
The HPE Aruba Networking AP-567 (R4W57A) is a rugged, entry-level Wi-Fi 6 (802.11ax) outdoor access point, purpose-built for extreme environments. With integrated 90° directional antennas, dual-radio 2x2 MIMO, and Bluetooth 5 + Zigbee IoT support, it delivers up to 1.49 Gbps aggregate data rate, making it ideal for outdoor campuses, warehouses, and industrial deployments.
Designed for harsh conditions, it endures temperatures from -40°C to +65°C, 165 mph wind speeds, and continuous exposure to moisture, dust, and salt spray. It also supports advanced security with WPA3, a built-in Trusted Platform Module (TPM), and Dynamic Segmentation for end-to-end policy enforcement.
Quick to deploy with Zero Touch Provisioning and managed through Aruba Central, this compact outdoor AP ensures robust, reliable, and secure connectivity in the most demanding environments.
| Specification | Details |
|---|---|
| Product Number | R4W57A |
| AP Type | Outdoor, hardened, dual-radio Wi-Fi 6 (2x2 MIMO for 5 GHz & 2.4 GHz) |
| Max Data Rate | 1.49 Gbps (HE80/HE20) |
| Integrated Antennas | 90°H x 90°V directional antennas |
| Antenna Gain | 2.4 GHz: 7.1 dBi 5 GHz: 6.8 dBi BLE/Zigbee: 3.0 dBi |
| IoT Support | Bluetooth 5 and 802.15.4 (Zigbee) radio |
| Mounting | Requires optional mounting kit |
| Power Consumption | Max: 15.6W Idle: 4.2W Deep-sleep: 1.7W (power source sold separately) |
| Physical Dimensions | 11 x 16.5 x 16.5 cm |
| Weight | 1.09 kg |
| Operating Temperature | -40°C to +65°C (including solar loading) |
| Environmental Protection | Weatherproof, shock/vibration resistant, 165 mph wind survival |
| Ports | 1x 10/100/1000BASE-T (RJ-45) Ethernet |
| Security Features | WPA3, Enhanced Open, TPM, Dynamic Segmentation |
| Certifications | Wi-Fi 6 Certified, TAA, CB Scheme, cTUVus, UL2043, Railway Standards |
| Warranty | Limited Lifetime Warranty |
