Description
Rugged and Reliable Outdoor Wi‑Fi 6 Connectivity
The HPE Aruba Networking AP-567 (JP) is a cost-effective, enterprise-grade outdoor access point that delivers high-performance Wi‑Fi 6 (802.11ax) connectivity in extreme environments. Designed with integrated 90° directional antennas and built-in support for Bluetooth 5 and Zigbee, this compact access point can withstand wind speeds up to 165 mph, extreme temperatures from -40°C to +65°C, and persistent moisture or contaminants.
Ideal for medium-density outdoor deployments like warehouses, manufacturing zones, and transportation hubs, the AP‑567 (JP) supports 1.49 Gbps aggregate throughput, OFDMA, MU-MIMO, and advanced client optimization features like ClientMatch. Enhanced security is built-in with WPA3, Dynamic Segmentation, and a TPM module for key protection.
| Specification | Details |
|---|---|
| Model Number | R4W47A |
| Wi‑Fi Standard | 802.11ax (Wi-Fi 6) |
| Radios | Dual radio (2x2 MIMO for 2.4 GHz and 5 GHz) |
| Max Aggregate Data Rate | Up to 1.49 Gbps |
| Antenna Type | Integrated directional (90°H x 90°V) antennas |
| Antenna Gain | 2.4 GHz: 7.1 dBi; 5 GHz: 6.8 dBi; BLE/Zigbee: 3.0 dBi |
| IoT Radios | Bluetooth 5 and 802.15.4/Zigbee |
| Power Consumption | Max: 15.6W; Idle: 4.2W; Deep Sleep: 1.7W |
| Mounting Options | Requires optional mounting kit (sold separately) |
| Ethernet Ports | 1x 10/100/1000BASE-T RJ-45 (E0) |
| Dimensions (W x H x D) | 16.5 x 16.5 x 11 cm |
| Weight | 1.09 kg |
| Operating Temperature | -40°C to +65°C |
| Environmental Tolerance | Dust, moisture, salt spray, airborne contaminants, wind (up to 165 mph) |
| Certifications | Wi-Fi 6 Certified, UL2043 Plenum, Railway (EN 50155), CE, FCC, CB, etc. |
| Security | WPA3, Enhanced Open, TPM, Dynamic Segmentation |
| Warranty | Limited Lifetime Warranty |
| Region Availability | Japan Only |
