Description
High-Performance Wi-Fi 6 for Harsh Outdoor Environments
The HPE Aruba Networking AP-577 (USF1) delivers robust Wi-Fi 6 connectivity with internal directional antennas, making it ideal for high-density outdoor venues like stadiums, transit stations, and industrial campuses. Built to thrive in extreme conditions, this TAA-compliant AP features a dual radio 2x2/4x4 design with integrated IoT support, including Bluetooth 5 and Zigbee.
The AP-577 offers up to 2.69 Gbps aggregate throughput, integrated AI-driven analytics, and Zero Touch Provisioning for rapid deployment. With support for WPA3, dynamic segmentation, and a Trusted Platform Module (TPM), this AP provides advanced security while simplifying policy enforcement.
Designed with a rugged, fully sealed enclosure, it withstands temperatures from -40˚C to +65˚C, heavy winds, and moisture — ensuring continuous performance in the most demanding environments.
| Specification | Details |
|---|---|
| Product Number | R4H38A |
| Model | AP‑577 (USF1) TAA |
| Wi-Fi Standard | IEEE 802.11ax (Wi‑Fi 6) |
| Radios | Dual Radio – 2.4 GHz 2x2 MIMO & 5 GHz 4x4 MIMO |
| Antenna Type | Internal 90° directional: 5 GHz (6.3 dBi), 2.4 GHz (6.4 dBi) |
| Maximum Throughput | 2.69 Gbps (aggregate) |
| Mounting Options | Optional mounting kits available |
| Power Consumption | 26.1W (single PoE), 32.0W (dual PoE); Idle: 14W; Deep Sleep: 2.9–3.9W |
| IoT Radios | Integrated Bluetooth 5 and 802.15.4 (Zigbee) |
| Security | WPA3, Dynamic Segmentation, TPM, Enhanced Open |
| Certifications | Wi‑Fi CERTIFIED 6, CB Scheme Safety, cTUVus, UL2043, Passpoint® R2 |
| Regulatory Compliance | FCC/ISED, CE, RED, EMC, IEC/EN/UL 62368-1, EN 50155, EN 50121 series |
| Enclosure & Operating Temperature | Ruggedized, -40˚C to +65˚C |
| Dimensions (HxWxD) | 13 x 23 x 22 cm |
| Weight | 2.1 kg |
| Warranty | Limited Lifetime Warranty |
