Description
The HPE Aruba Networking AP‑755 (RW) is part of the flagship 750 Series Wi‑Fi 7 (802.11be) campus access points, offering ultra-fast, high-capacity wireless performance for enterprise, healthcare, education, industrial, and IoT environments. This 5-pack of tri-radio access points delivers robust coverage across 2.4 GHz, 5 GHz, and 6 GHz bands, reaching up to 18.7 Gbps aggregate throughput and supporting dual 10G Ethernet for hitless failover.
With integrated Bluetooth 5.4, Zigbee, dual USB ports, and patented Ultra Tri-band filtering, these access points provide comprehensive wireless, locationing, and IoT capabilities. Built-in GNSS receivers, barometric sensors, and advanced power management features also enable precision indoor location and energy efficiency—ideal for high-density, mission-critical deployments.
| Specification | Details |
|---|---|
| Product Number | S0H10A |
| AP Model | AP‑755 (RW) |
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be) |
| Radios | Tri-Radio (2.4 GHz, 5 GHz, 6 GHz) |
| MIMO | 4x4 MIMO per band |
| Max Data Rate | Up to 18.7 Gbps (28.8 Gbps with optional dual-radio mode) |
| Antenna Type | Integrated down-tilt omni-directional antennas |
| Antenna Gain | 5.3 dBi (2.4 GHz), 6.0 dBi (5/6 GHz) |
| Ports | 2x 10GbE (RJ-45), 2x USB 2.0 (Type A), 1x Console (micro-USB) |
| Security | WPA3, MACsec, Enhanced Open, TPM |
| IoT Support | 2x Bluetooth 5.4, 802.15.4 (Zigbee), 2x USB |
| Locationing | GNSS, barometric sensor, 802.11az (FTM) |
| Power Consumption | Max 40W (PoE), 35W (DC); Idle: 12W/14W |
| Mounting | Pre-installed bracket; kits sold separately |
| Operating System | ArubaOS 10 |
| Certifications | Wi-Fi Alliance, UL2043, CE, FCC/ISED, RED, EMC, LVD |
| Form Factor | Indoor ceiling mount |
| Warranty | Limited lifetime warranty |
| Differentiator | Available in all regions except US, Japan, Israel, and Egypt |
| Pack Size | 5-Pack |
