Description
The HPE Aruba Networking CX 5420 24p SFP 1G Module (S0U67A) is a high-performance, intelligent line card designed for the CX 5420 modular Layer 3 switch series. Featuring 24 SFP 1G ports, this module delivers enterprise-grade access with low latency, high throughput, and robust security for small to medium campus and branch networks.
Built on the Gen7 ASIC architecture, it provides wire-speed switching with 714 Mpps throughput and supports flexible programmability for evolving application needs. With support for HPE Aruba Networking Virtual Switching Extension (VSX), MACsec hardware, and integrated Network Analytics Engine (NAE), the CX 5420 series ensures continuous monitoring, rapid troubleshooting, and secure segmentation.
Whether you're deploying IoT, Wi-Fi 6, or high-demand enterprise services, this module supports automation, scalability, and power efficiency—all backed by the AOS-CX operating system and unified management through Aruba Central or CLI.
| Specification | Details |
|---|---|
| Product Number | S0U67A |
| Port Type | 24 x SFP 1G |
| Module Slots | 6 half-width line card slots supported |
| Latency | 2.5 microseconds |
| Throughput | 714 Mpps |
| Switching Capacity | 960 Gbps (480 Gbps in + 480 Gbps out) |
| Memory | 16GB DDR4 SODIMM with ECC |
| Flash Storage | 32GB eMMC |
| Packet Buffer | 64MB dynamically shared |
| MACsec Capability | Hardware capable (software support in future releases) |
| Management | Aruba Central, CLI, SNMPv2c/v3, RMON, Multi-Edit Software |
| Power Supply Support | 4 field-replaceable, hot-swappable slots |
| Input Voltage | 100–127 / 200–240 VAC |
| Power Consumption | 1600W @ 200–240 VAC; 1000W @ 100–127 VAC |
| Operating Temperature | 0°C to 45°C (derate 1°C every 1000 ft above 5000 ft) |
| Dimensions (H x W x D) | 4.3 x 21.3 x 22.9 cm |
| Weight | 898.1 g |
| PoE Capability | IEEE 802.3bt (up to 90W Class 8 per port – chassis-level feature) |
| Compatible With | HPE Aruba Networking CX 5420 Chassis Switch Series |
