Description
The HPE Aruba Networking CX 6200F 48G Class4 PoE 4SFP+ 740W Switch is a modern Layer 3 access switch tailored for SMBs, branch offices, and enterprise edge networks. Designed with a fully programmable AOS-CX operating system and powered by Gen7 ASICs, it delivers high-speed, low-latency performance and robust automation and analytics.
With 48 Class 4 PoE+ ports (up to 30W each) and 4 SFP+ uplinks, this model supports up to 740W PoE power budget—ideal for powering access points, IP phones, cameras, and IoT devices. It offers intelligent insights with the Aruba Network Analytics Engine and can be stacked up to 8 units using VSF technology.
Built for flexibility, manageability, and high availability, this switch supports hot-swappable redundant power and fans, REST APIs for automation, and dynamic segmentation for secure and simplified access control.
| Specification | Details |
|---|---|
| Product Number | JL728B#ABA |
| Switch Type | Layer 3 Managed Stackable Switch |
| Ports | 48x 10/100/1000BASE-T (Class 4 PoE+)4x 100M/1/10G SFP+ uplinks |
| PoE Budget | 740W total; 30W max per port |
| PoE Standards | IEEE 802.3af, 802.3at |
| Console Ports | 1x USB-C Console1x RJ-45 Console1x USB Type-A Host1x OOBM |
| Stacking | Up to 8 members using Virtual Switching Framework (VSF) |
| Stacking Distance | Up to 10 km (with long-range transceivers) |
| CPU | Quad Core ARM Cortex-A72 @ 1.8 GHz |
| Memory / Flash | 8 GB DDR4 RAM, 16 GB eMMC Flash |
| Latency | 1 Gbps: 2.28 μs10 Gbps: 1.46 μs |
| Throughput | Up to 130.9 Mpps |
| Switching Capacity | 176 Gbps |
| Input Voltage | 100V–120V / 200V–240V AC |
| Power Consumption | 76W (at 230 VAC) |
| Mounting | Rack-mountable |
| Form Factor | 1U |
| Dimensions (WxDxH) | 17.4 x 12.9 x 1.73 in |
| Weight | 11.24 lbs (max, depending on model) |
| Cooling | Front and side-to-back airflow with optional redundant fan support |
| Software | ArubaOS-CX with Aruba Network Analytics Engine (NAE) |
| Management Options | Aruba Central, Web GUI, CLI, REST API, Aruba CX Mobile App |
| Automation & Monitoring | Python/REST APIs, TSDB, Switch Multi-Edit Software, Dynamic Segmentation |
