Description
The Edge-Core AS7816-64X-O-AC-F-US-R is a high-performance Top-of-Rack (TOR) or spine switch built for next-generation data centers and cloud environments. Designed for maximum scalability and open networking flexibility, it supports 64 × QSFP28 ports delivering full line-rate L2/L3 switching at 100GbE, 40GbE, 25GbE, or 10GbE speeds via breakout cables.
Powered by the Broadcom StrataXGS Tomahawk II ASIC and an Intel Xeon D-1518 quad-core CPU, this switch offers 12.8 Tbps switching capacity and 9.5 bpps forwarding performance in a compact 2RU form factor. It is pre-loaded with the Open Network Install Environment (ONIE) to support installation of compatible open-source and commercial Network Operating Systems (NOS), including Open Network Linux (ONL) and SONiC.
Built for reliability and efficiency, the AS7816-64X-O-AC-F-US-R includes dual hot-swappable AC power supplies, 3+1 redundant fans, and front-to-back (port-to-power) airflow to align with modern data-center cooling architectures. It complies with major international EMI, safety, and environmental standards, making it a trusted platform for open, disaggregated network deployments.
| Category | Specification |
|---|---|
| Model Number | 7816-64X-O-AC-F-US-R |
| Product Type | Bare-Metal Open Network Switch |
| Form Factor | 2RU rack-mountable |
| Switch Silicon | Broadcom BCM56970 Tomahawk II |
| CPU | Intel Xeon D-1518 quad-core 2.4 GHz |
| Memory | 16 GB DDR3L (8 GB × 2, ECC) |
| Storage | 128 GB M.2 SSD + reserve mSATA connector |
| Packet Buffer | 42 MB integrated |
| Switching Capacity | 12.8 Tbps (full duplex) |
| Forwarding Rate | 9.5 bpps |
| Ports | 64 × QSFP28 (100 GbE/40 GbE or 4 × 25 GbE/4 × 10 GbE breakouts) |
| Management Interfaces | 1 × RJ-45 serial console, 1 × RJ-45 100/1000BASE-T management, 1 × USB Type-A |
| Airflow | Port-to-Power (front-to-back) |
| Power Supplies | Dual AC PSUs (850 W, hot-swappable, load-sharing) |
| Fans | 3 + 1 redundant, hot-swappable |
| Operating Temperature | 0 °C to 45 °C (32 °F to 113 °F) |
| Operating Humidity | 5 % – 95 % non-condensing |
| Dimensions (W × D × H) | 43.8 × 58.0 × 8.8 cm (17.2 × 22.8 × 3.5 in) |
| Weight | 14.11 kg (31.1 lb) |
| Software Environment | ONIE software installer pre-loaded; supports Open Network Linux and SONiC NOS |
| Supported APIs | Redfish Management API (OCP compliant) |
| Compliance & Safety | CE Mark, FCC Part 15 Class A, VCCI Class A, UL, CB, RoHS-6, WEEE Directive |
| Warranty | 3-Year Hardware Warranty (terms may vary by region) |
