Description
The Edgecore AS9726-32DB is a high-performance, open-network 400G data center switch designed for large-scale cloud, enterprise, and service provider environments. Featuring 32 x QSFP56-DD ports, the switch delivers 12.8 Tbps switching capacity and supports a range of interface configurations — including 400G, 200G, 100G, 40G, 25G, and 10G via breakout options.
Powered by the Broadcom Trident 4 chipset and an Intel® Pentium® D1519 processor, the AS9726-32DB provides exceptional throughput and programmability for high-density leaf deployments. It includes dual hot-swappable 1500W AC power supplies, 5+1 redundant fans with back-to-front airflow, and comes preloaded with Open Network Install Environment (ONIE) for flexible installation of open-source or commercial network operating systems.
Engineered for efficiency and scalability, the Edgecore AS9726-32DB ensures robust connectivity for next-generation 400G infrastructures.
| Category | Specification |
|---|---|
| Model | Edgecore AS9726-32DB-O-AC-B-UN |
| Form Factor | 1U Rack-Mountable |
| Switch Silicon | Broadcom BCM56880 (Trident 4) |
| CPU | Intel® Pentium® D1519, 4-Core, 1.5 GHz |
| Memory | 16 GB DDR4 SO-DIMM (8GB x2) with ECC |
| Storage | 64 GB M.2 NVMe SSD |
| Switching Capacity | 12.8 Tbps full duplex |
| Forwarding Rate | 5.4 Bpps |
| Packet Buffer Size | 132 MB SmartBuffer |
| MAC Addresses | Up to 384K |
| Ports | 32 x QSFP56-DD 400G Ethernet ports |
| Port Modes Supported | 1x400G, 2x200G, 4x100G, 1x100G QSFP28, 1x40G QSFP+, 4x25G, 4x10G |
| Management Ports | 1 x RJ-45 console, 1 x Micro USB console, 1 x RJ-45 1G management, 2 x SFP+ 10G management, 1 x USB 3.0 storage |
| Airflow | Back-to-Front |
| Power Supplies | Dual hot-swappable, load-sharing 1500W AC PSU |
| AC Input Range | 200–240 VAC, 50–60 Hz |
| Power Consumption (Max) | 714 W @100VAC / 653 W @240VAC (without transceivers) |
| Fans | 5+1 redundant, hot-swappable modules |
| Dimensions (W x D x H) | 43.84 × 59 × 4.35 cm (17.26 × 23.23 × 1.71 in.) |
| Weight | 11.85 kg (26.12 lb) with 2 PSUs and 6 fans |
| Operating Temperature | 0°C to 35°C (B2F airflow) |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 5%–95% non-condensing |
| Regulatory Compliance | EN 55032 Class A, FCC Class A, UL/IEC 62368-1, RoHS 2.0, WEEE |
| Software | Preloaded with ONIE; supports open-source and commercial NOS options |
| Warranty | Refer to Edgecore regional terms |
