Description
The ASUS RS720-E10-RS12E-16K10L is a scalable, high-performance 2U rackmount server designed for enterprise, AI, and HPC workloads. Powered by dual-socket 3rd Gen Intel® Xeon® Scalable processors with support for CPUs up to 270W TDP, this server offers up to 32 DIMM slots and 6TB of DDR4 memory capacity for demanding computing environments. Its 9 PCIe 4.0 slots, OCP 3.0 mezzanine support, and 12 front hot-swap drive bays (supporting SAS/SATA/NVMe) deliver outstanding expansion flexibility.
The RS720-E10-RS12E-16K10L supports up to four dual-slot GPUs such as the NVIDIA A100, enabling scalable acceleration for deep learning and virtualization. Enhanced security is ensured with PFR FPGA platform Root-of-Trust and TPM 2.0. The integrated ASMB10-iKVM module and ASUS Control Center software offer robust out-of-band management and monitoring capabilities. With flexible cooling options—including air and liquid configurations—the RS720-E10 delivers exceptional efficiency and reliability for data center and enterprise deployments.
| Category | Specification |
|---|---|
| Processor Support | 2 × Socket P+ (LGA 4189) for 3rd Gen Intel® Xeon® Scalable Processors (up to 270W) |
| Chipset | Intel® C621A |
| Memory Slots | 32 DIMMs (8-channel per CPU, 16 per CPU) |
| Memory Type | DDR4 3200/2933 RDIMM/LRDIMM/LRDIMM 3DS, Intel® Optane™ DCPMM |
| Max Memory Capacity | Up to 6TB |
| Expansion Slots | 9 × PCIe 4.0 (x16/x8 configurations) + 1 × OCP 3.0 mezzanine slot |
| Storage Bays | 12 × 3.5"/2.5" hot-swap bays (8 × NVMe/SATA/SAS + 4 × SATA/SAS); optional 2 × rear 2.5" bays |
| M.2 Slots | 2 × M.2 (2280/2260, PCIe Gen4 x4) |
| Storage Controllers | Intel® RSTe and VROC RAID (0,1,5,10,50); optional ASUS PIKE II 3008/3108 SAS cards |
| Networking | Optional: Quad-Port Intel® I350-AM4 1G or Dual-Port Intel® X710-AT2 10G; 1 × Mgmt LAN (RJ-45) |
| Graphics | ASPEED AST2600 (64MB) |
| Front I/O Ports | 2 × USB 3.2 Gen 1 |
| Rear I/O Ports | 2 × USB 3.2 Gen 1, 1 × VGA, 1 × Mgmt LAN, 2–4 × NIC ports (depends on LAN module) |
| Management | ASUS Control Center (Classic), ASMB10-iKVM (KVM-over-IP) |
| Power Supply | 1+1 Redundant 1600W 80 PLUS Platinum or 2400W 80 PLUS Titanium |
| Cooling Options | Air or liquid-cooled (Asetek D2C liquid-cooling technology supported) |
| Security | PFR FPGA Root-of-Trust, TPM 2.0 |
| Dimensions (W × D × H) | 449 × 840 × 88.1 mm (2U) |
| Net Weight / Gross Weight | 18.2 kg / 26.9 kg |
| Operating Temperature | 10°C – 35°C |
| Operating Systems | Windows Server, RHEL, SuSE, CentOS, Ubuntu, VMware |
