Description
The Kramer VP-440H2 is a compact, high-performance 4K60 (4:4:4) presentation switcher/scaler designed for modern meeting rooms, classrooms, and collaborative environments. Equipped with three HDMI inputs, one VGA input, and one HDBaseT input with PoE, it provides seamless switching, powerful scaling, and simultaneous HDMI and HDBaseT outputs for flexible signal distribution.
This professional-grade device integrates Kramer’s PixPerfect™ scaling technology for crystal-clear image reproduction and supports advanced HDMI 2.0 and HDCP 2.2 compliance, ensuring compatibility with current and future 4K sources. With robust audio handling—including analog and embedded audio, DSP-based processing, and microphone support—the VP-440H2 delivers a complete AV switching and presentation solution.
Built for reliability and ease of use, it features auto-input switching, constant output sync, flexible control options (RS-232, Ethernet with Web UI, OSD, front panel), and fully certified HDBaseT signal extension up to 100 meters. Ideal for corporate installations, education spaces, and conference environments requiring high-quality 4K signal management.
| Category | Details |
|---|---|
| Video Inputs | 3 HDMI (HDMI 2.0, HDCP 2.2), 1 VGA (15-pin HD), 1 HDBaseT (RJ-45) |
| Audio Inputs | 4 unbalanced stereo (3.5mm), 1 microphone (6.3mm, selectable 48V phantom power) |
| Video Outputs | 1 HDMI (HDMI 2.0, HDCP 2.2), 1 HDBaseT (RJ-45) |
| Audio Outputs | 1 unbalanced stereo (3.5mm) |
| Max Resolution | 4K@60Hz (4:4:4) |
| Input Resolutions | HDMI/HDBT: 480i–4K60; PC: up to 1920x1200RB@60Hz |
| Output Resolutions | 480p–4K60 (4:4:4)* |
| Switching Time | 2–3 seconds |
| Video Latency | < 2 frames |
| Scaling Technology | PixPerfect™ precision pixel-mapping |
| Audio Features | DSP EQ, mixing, delay; AFV (Audio-Follow-Video) |
| Control Options | Front panel, RS-232, OSD, Ethernet (Web UI) |
| HDBaseT Range | Up to 100m (330 ft) with recommended cables |
| Power | 48V DC, 850mA |
| Operating Temperature | 0° to +40°C (32° to 104°F) |
| Product Dimensions (W x D x H) | 21.46 × 16.30 × 4.36 cm (8.45" × 6.42" × 1.72") |
| Product Weight | 1.5 kg (3.3 lbs) |
| Included Accessories | Power supply |
| Optional Accessories | RK-1 rack adapter |
