Description
The CyberPower BM120V30ATY is a high-capacity 3-phase modular UPS battery module designed to extend runtime and ensure continuous power protection for mission-critical infrastructure. Built with ten (10) 12VDC 9Ah VRLA batteries, this modular unit provides reliable backup energy storage for compatible CyberPower 3-Phase Modular UPS battery cabinets.
With a hot-swappable design, the BM120V30ATY allows battery replacement or runtime expansion without interrupting connected equipment—ideal for data centers, industrial power environments, and enterprise installations. Encased in a durable metal housing and backed by a one-year limited warranty, it is engineered for long-term performance and scalability.
| Specification | Details |
|---|---|
| Brand | CyberPower |
| Manufacturer Part Number | BM120V30ATY |
| Product Type | Modular UPS Battery Module |
| UPS Compatibility | CyberPower 3-Phase Modular UPS Systems |
| Nominal Output Voltage | 120 VAC |
| Battery Voltage | 120V DC |
| Battery Configuration | Ten (10) 12VDC 9Ah batteries |
| Battery Type | VRLA (Valve-Regulated Lead Acid) |
| Hot-Swappable | Yes |
| Form Factor | Modular |
| Rack Units | 3U |
| Color | Silver |
| Material | Metal Construction |
| Dimensions (W x H x D) | 236 x 117 x 610 mm (9.3 x 4.6 x 24 in.) |
| Weight | 33.61 kg (74.1 lb) |
| Shipping Weight | 34.52 kg (76.1 lb) |
| Operating Temperature | 0 – 40°C (32 – 104°F) |
| Operating Humidity | 0 – 95% Non-Condensing |
| Certifications | RoHS, cTUVus, UL1778, FCC Class A |
| Warranty | One-Year Limited Warranty |
