Description
The Belkin Universal 2nd Gen Secure KVM Switch is engineered for mission-critical environments that demand uncompromising security, reliability, and performance. Designed to meet NIAP Protection Profile PSD 4.0 requirements, this 8-port single-head KVM enables secure, centralized control of multiple computers operating across different security domains without risk of data leakage.
Built with advanced isolation architecture, the switch enforces strict unidirectional data flow for USB, audio, and video channels, ensuring complete separation between connected systems. Its always-on active anti-tamper protection safeguards against physical intrusion, immediately disabling the device if tampering is detected.
Supporting high-resolution video up to 4K at 60Hz via DisplayPort and HDMI, this secure KVM delivers both clarity and performance for demanding operational environments. Integrated CAC support, USB device filtering, and administrator-controlled configurations provide enhanced usability without compromising security.
Ideal for government, defense, and enterprise deployments, the Belkin Secure KVM ensures trusted access, operational continuity, and compliance with the most stringent cybersecurity standards.
| Specification | Details |
|---|---|
| Brand | Belkin |
| Product Type | Secure KVM Switch |
| Number of Ports | 8-Port |
| Head Configuration | Single Head |
| Security Compliance | NIAP Protection Profile PSD 4.0 |
| Video Interfaces | DisplayPort 1.2 / HDMI 2.0 |
| Maximum Resolution | Up to 3840 x 2160 @ 60Hz |
| Number of Users Supported | 1 |
| Supported Computers | Up to 8 |
| USB Support | USB keyboard, mouse, and CAC |
| CAC Support | Yes (Common Access Card) |
| Audio Support | Analog audio output (no microphone input) |
| Data Flow Security | Unidirectional data flow with hardware enforcement |
| USB Device Filtering | Blocks unauthorized USB devices |
| Anti-Tamper Protection | Always-on active anti-tamper system |
| Firmware Security | Non-reprogrammable firmware |
| Channel Selection | Front-panel push buttons |
| LED Indicators | Port status and activity indicators |
| Power Requirements | 100–240 VAC, 50/60Hz |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 0–80% non-condensing |
| Dimensions | 17.2 x 1.6 x 8.1 inches |
| Weight | Approx. 9.8 lbs |
| Mounting Options | Desktop or rack-mount |
| Warranty | 3-Year Limited Warranty |
