Description
The BenQ ST6504 is a 65-inch 4K UHD digital signage display engineered for clear, dynamic communication across campuses, corporate environments, and public spaces. With 3840 × 2160 resolution and 350 nits brightness, it delivers sharp visuals and vibrant color with 99% sRGB coverage, ensuring messages are easily seen and understood.
Designed for reliable 18/7 operation, the ST6504 runs on Android 14 with 4GB system memory and 32GB storage, providing a powerful, all-in-one signage solution without the need for an external media player. Built-in content management compatibility with X-Sign 3.0, wireless screen sharing via InstaShare 2, and centralized control through DMS make deployment and management simple and efficient.
With dual HDMI inputs, LAN connectivity, USB ports, RS-232 control, and integrated 12W × 2 speakers, the ST6504 supports flexible installation in both landscape and portrait orientations. Its slim 10.8 mm bezel and VESA 400 × 400 mounting ensure a clean, professional appearance in any setting.
| Specification | Details |
|---|---|
| Screen Size | 65" |
| Resolution | UHD 3840 × 2160 |
| Brightness | 350 nits |
| Contrast Ratio | 1200:1 |
| Viewing Angle (H/V) | 178° / 178° |
| Response Time | 8 ms |
| Color Gamut | 99% sRGB, 72% NTSC |
| Backlight Life | 30,000 hours |
| Panel Surface | Anti-Glare, 25% Haze |
| Operating Hours | 18/7 |
| Display Orientation | Landscape / Portrait |
| Operating System | Android 14.0 |
| System Memory | 4GB |
| Storage | 32GB |
| Power Supply | 100V–240V, 50–60Hz |
| Typical Power Consumption | 76W |
| Energy Efficiency | ENERGY STAR® 8.0 Certified |
| HDMI Inputs | 2 × HDMI 2.0 |
| USB Ports | 2 × USB Type-A (2.0) |
| LAN | 1 × RJ45 (10/100 Mbps) |
| RS-232 (In) | Yes |
| Audio Output | 3.5 mm Audio Out |
| Internal Speakers | 12W × 2 |
| Dimensions (W × H × D) | 1452.9 × 829.2 × 59.7 mm |
| Net Weight | 16.9 kg |
| VESA Mount | 400 × 400 mm (4 × M6 × 15L) |
