Description
The AddOn Cisco® QSFP-100GB-130231-20-E-C Compatible Transceiver is a high-performance, hot-swappable 100GBase-OWDM QSFP28 optical module designed for high-speed data center, enterprise, and access network applications. Operating over single-mode fiber (SMF) with a center wavelength of 1302.31nm, this transceiver supports data rates up to 106.25Gbps (PAM4) and delivers reliable performance over distances of up to 20km via a duplex LC connector.
Engineered to meet QSFP28 MSA and IEEE 802.3bs standards, this module features a high-sensitivity APD receiver, integrated Digital Optical Monitoring (DOM) for real-time parameter access, and a robust operating temperature range of -5°C to +80°C. It is fully compliant with the Trade Agreements Act (TAA) and guaranteed 100% compatible with Cisco® equipment. Each unit is uniquely serialized, programmed, and rigorously tested to ensure identical functionality to OEM equivalents — all backed by AddOn’s limited lifetime warranty.
| Specification | Details |
|---|---|
| SKU | QSFP-100GB-130231-20-E-C-AO |
| Form Factor | QSFP28 |
| Data Rate | 106.25 Gbps (PAM4) |
| Application | 100GBase-OWDM Ethernet |
| Wavelength | 1302.31 nm (OW302, O-Band) |
| Wavelength Range | 1301.91 – 1302.71 nm |
| Reach / Distance | 20 km over SMF |
| Connector Type | Duplex LC |
| Optical Modulation Format | PAM4 |
| Launch Power (Avg.) | 0 to +3.4 dBm |
| OMA (Outer Optical Modulation Amplitude) | 3.0 to +6.4 dBm |
| Extinction Ratio | ≥ 5.0 dB |
| Receiver Sensitivity (OMAouter) | -11.6 dBm (stressed) |
| Receiver Input Power | -15.7 to -3 dBm |
| Operating Temperature | -5°C to +80°C |
| Power Supply Voltage | +3.3V |
| Power Consumption | 4.4W (typical at 25°C) |
| Management Interface | I²C |
| Compliance Standards | QSFP28 MSA, IEEE 802.3bs, 100G Lambda MSA |
| Digital Diagnostic Monitoring (DOM) | Supported |
| Compatible OEM | Cisco® |
| Warranty | Limited Lifetime |
| Compliance | TAA, RoHS, Lead-Free |
