Description
The AddOn Cisco® DWDM-SFP10G-49.32-100-I-AO is a high-performance, TAA-compliant 10GBase-DWDM SFP+ transceiver designed for demanding optical networking environments. Operating on the 1549.32 nm wavelength (ITU Channel 35) within the C-Band 100 GHz grid, this hot-swappable module delivers up to 100 km reach over single-mode fiber (SMF) through an LC duplex connector.
Engineered for reliability and seamless integration, the transceiver is 100% compatible with Cisco® equipment, supporting 8x/10x Fibre Channel and 10G Ethernet over DWDM in access, metro, and enterprise applications. With Digital Optical Monitoring (DOM), operators can track real-time performance metrics, while industrial-grade operation (-40 °C to +85 °C) ensures stable performance in harsh environments.
Built to SFF-8432 and SFF-8472 standards and offering robust ESD protection, low EMI, and RoHS compliance, this transceiver combines performance, reliability, and cost-efficiency — backed by AddOn’s industry-leading quality assurance and limited lifetime warranty.
| Parameter | Specification |
|---|---|
| SKU | DWDM-SFP10G-49.32-100-I-AO |
| Form Factor | SFP+ |
| Data Rate | 10.3125 Gbps |
| Application | 10GBase-DWDM, 8x/10x Fibre Channel |
| Wavelength | 1549.32 nm (ITU Channel 35, C-Band 100 GHz) |
| Transmission Distance | Up to 100 km |
| Fiber Type | Single-Mode Fiber (SMF) |
| Connector Type | Duplex LC |
| Digital Optical Monitoring (DOM) | Supported |
| Operating Temperature | -40 °C to +85 °C (Industrial) |
| Transmit Power | +1.0 dBm to +4.0 dBm |
| Receiver Sensitivity | ≤ -26 dBm |
| Extinction Ratio | ≥ 9 dB |
| Side Mode Suppression Ratio | ≥ 30 dB |
| Receiver Overload | -7 dBm |
| Dispersion Limited Distance | 100 km |
| Power Dissipation | ≤ 1.8 W |
| Compliance Standards | SFF-8432, SFF-8472, RoHS 2.0, TAA |
| Certifications | FCC Part 15, EN55022:2010, FDA 21CFR, EN60950-1, IEC 60825-1/2 |
| Hot Pluggable | Yes |
| Warranty | Limited Lifetime Warranty |
