Description
The AddOn Cisco® QDD-400G-DR4-S Compatible QSFP-DD Transceiver delivers exceptional 400GBase-DR4 performance over single-mode fiber (SMF) with transmission distances up to 500 meters using a 1310nm wavelength via an MPO-12 connector. Designed to meet or exceed OEM specifications, this transceiver ensures seamless integration into Cisco® network environments and is fully compliant with IEEE 802.3bs, QSFP-DD MSA, and CMIS 4.0 standards.
Each unit is programmed, uniquely serialized, and rigorously tested to guarantee identical initialization and operation as the original Cisco® module. It supports Digital Optical Monitoring (DOM) for real-time performance tracking and is TAA compliant, making it ideal for government and enterprise deployments. With robust ESD protection, low power consumption, and reliable Class 1 laser safety, this module is a high-performance solution for data center, enterprise, and access network applications.
| Specification | Details |
|---|---|
| SKU | QDD-400G-DR4-S-AO |
| Brand | AddOn |
| Compatible OEM | Cisco® |
| Form Factor | QSFP-DD |
| Data Rate | 400GBase-DR4 |
| Wavelength | 1310nm |
| Fiber Type | Single-Mode Fiber (SMF) |
| Connector Type | MPO-12 |
| Maximum Distance | Up to 500m |
| Compliance Standards | IEEE 802.3bs, QSFP-DD MSA, CMIS 4.0 |
| DOM Support | Yes |
| Operating Temperature | 0°C to 70°C |
| Power Dissipation | Max. 9 W |
| Hot-Plug Current (Peak) | 3600 mA |
| Supply Voltage | 3.135V – 3.465V |
| Center Wavelength Range | 1304.5nm – 1317.5nm |
| Extinction Ratio (Per Lane) | ≥ 3.5 dB |
| Receiver Sensitivity (OMAouter) | ≤ -4.4 dBm |
| Transmit OMAouter (Per Lane) | -0.8 dBm to 4.2 dBm |
| TAA Compliant | Yes |
| RoHS Compliant / Lead-Free | Yes |
| Application | Data Center, Access, Enterprise Networks |
| Warranty | Limited Lifetime Warranty |
