Description
The Cisco CW9176D1-CFG Wireless Access Point is a high-performance Wi-Fi 7 (802.11be) enterprise access point designed for demanding indoor environments requiring high throughput, low latency, and precise location services. Featuring a tri-band, tri-radio 4x4 architecture, this model supports 2.4 GHz, 5 GHz, and 6 GHz operation with advanced capabilities such as Multi-Link Operation (MLO), 320 MHz channels, and 4K-QAM for next-generation wireless performance.
The CW9176D1 includes an integrated Ultra-Wideband (UWB) radio for high-accuracy location tracking, along with Bluetooth LE, IoT radio, and GNSS/GPS support to enable advanced analytics, asset tracking, and location-based services. Its directional internal antennas make it ideal for targeted coverage in offices, classrooms, hospitals, and high-density enterprise deployments.
Designed as a global-use access point, the CW9176D1-CFG simplifies worldwide deployments by dynamically adapting to regulatory domains and supporting both Cisco Catalyst and Cisco Meraki cloud management architectures. With 10G Multigigabit Ethernet, intelligent power optimization, and enterprise-grade security, it delivers a future-ready wireless foundation for modern networks.
| Category | Specification |
|---|---|
| Product Series | Cisco Wireless 9176 Series |
| Model | CW9176D1-CFG |
| Wireless Standard | Wi-Fi 7 (802.11be), backward compatible with Wi-Fi 6E / Wi-Fi 6 |
| Radios | 3 radios (Tri-radio architecture) |
| Frequency Bands | 2.4 GHz, 5 GHz, 6 GHz |
| Spatial Streams | 4x4 MU-MIMO per band |
| Maximum Channel Width | Up to 320 MHz (6 GHz) |
| Modulation | Up to 4096-QAM (4K-QAM) |
| Maximum PHY Data Rate | Up to 23 Gbps (aggregate) |
| Antenna Type | Internal directional antennas |
| Ultra-Wideband (UWB) | Integrated UWB radio |
| Bluetooth | Bluetooth Low Energy (BLE) |
| IoT Radio | Integrated IoT radio |
| GNSS / GPS | Built-in GNSS/GPS antenna |
| Ethernet Interface | 1 × 100M/1G/2.5G/5G/10G Multigigabit Ethernet (RJ-45) |
| Power Options | 802.3bt (UPOE), 802.3at (PoE+), 802.3af (staging only) |
| Maximum Power Consumption | Up to 39W |
| Management Platforms | Cisco Catalyst 9800, Cisco Catalyst Center, Cisco Meraki |
| Deployment Type | Indoor |
| Regulatory Domain | Global |
| Mounting | Ceiling or wall mount |
| Use Case | Enterprise, high-density indoor environments |
