Description
The NVIDIA Mellanox MCX623105AN-VDAT is a ConnectX-6 Dx EN Ethernet adapter with a single QSFP56 port. It supports 1, 10, 25, 40, 50, 100, and 200Gb/s Ethernet and connects over PCIe Gen 4.0 x16, with backward compatibility to Gen 3.0. Crypto and Secure Boot are both disabled on this model. It ships with a tall bracket in a half-height, half-length form factor.
ConnectX-6 Dx provides RoCE, NVGRE and VXLAN overlay offloads, Open vSwitch offload through ASAP², SR-IOV, NVMe over Fabrics target offloads, and IEEE 1588v2 PTP with an integrated hardware clock.
Technical Specifications:
| Specification | Details |
|---|---|
| Brand | NVIDIA Mellanox |
| MPN | MCX623105AN-VDAT |
| NVIDIA SKU | 900-9X6AG-0018-ST0 |
| Product Type | Ethernet Adapter Card |
| Controller | ConnectX-6 Dx |
| Form Factor | HHHL, 5.59 x 2.71 in (142.00 x 68.90mm) |
| Ports | 1 x QSFP56 (copper and optical) |
| Ethernet Data Rate | 1/10/25/40/50/100/200Gb/s |
| Key Protocols | 200GBASE-CR4/KR4/SR4, 100GBASE-CR4/KR4/SR4/CR2/KR2/SR2, 50GBASE-R2/R4, 40GBASE, 25GBASE-R, 10GBASE, 1000BASE-CX/KX |
| Host Interface | PCIe Gen 3.0/4.0, 16.0GT/s x16 |
| Crypto | Disabled |
| Secure Boot | Disabled |
| Bracket | Tall bracket |
| Typical Power (passive cables, Gen 4.0) | 16.94W |
| Maximum Power (passive cables, Gen 4.0) | 24W |
| Max Power per QSFP56 Port | 5W |
| Airflow (heatsink to port, 55°C) | 600LFM passive cable; 950LFM active 4.55W cable |
| Operating Temperature | 0°C to 55°C |
| Non-Operating Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 85% RH |
| Operating Altitude | 3050m |
| Safety / EMC | CB, cTUVus, CE / CE, FCC, VCCI, ICES, RCM |
| Compliance | RoHS |
