Description
The Crestron CCC-110-Z Collab Compute delivers a powerful, AI-ready foundation for modern Zoom Rooms environments. Engineered with an Intel Core Ultra 5 processor, this enterprise-grade conferencing compute solution enables intelligent meeting experiences, real-time collaboration enhancements, and seamless integration across advanced AV ecosystems.
Designed for scalability and flexibility, the CCC-110-Z supports up to three displays, multiple USB-connected audio and video peripherals, and integration with Crestron touch screens for intuitive room control. Its robust connectivity options, including Wi-Fi 7, multiple Ethernet ports, and high-speed USB interfaces, ensure reliable performance in demanding enterprise deployments.
With built-in support for BYOD workflows, centralized management via XiO Cloud, and enterprise-grade security, the CCC-110-Z is ideal for organizations seeking a future-ready conferencing infrastructure that combines performance, flexibility, and streamlined deployment.
| Specification Category | Details |
|---|---|
| Processor | Intel Core Ultra 5 125H |
| Memory | 32 GB DDR5 Dual Channel SODIMM |
| Storage | 256 GB SSD |
| Graphics | Intel ARC Graphics |
| Operating System | Windows 11 Enterprise IoT Edition |
| Display Support | Up to three displays via HDMI and USB-C |
| HDMI Output | 3 x HDMI 2.0b outputs (HDCP 2.3, EDID, CEC) |
| HDMI Input | 1 x HDMI 2.0b content input |
| USB Type-C | 1 x USB-C 3.2 Gen 2 (DisplayPort Alt Mode, video + data) |
| USB Type-A (Rear) | 5 x USB 3.0 (10 Gbps) |
| USB Type-A (Front) | 2 x USB 2.0 (480 Mbps) |
| Network Interfaces | 1 x Intel I219-LM, 2 x Intel I210 Gigabit Ethernet |
| PoE+ Port | 1 x RJ-45 PoE+ (IEEE 802.3at Type 2, 30W) |
| Wireless Connectivity | Wi-Fi 7 (Intel BE200, 2x2 MIMO) |
| Bluetooth | Bluetooth 5.4 |
| DM Input | 1 x RJ-45 DM input (HDCP 2.3, EDID pass-through) |
| Audio/Video Device Support | Up to 4 USB-connected AV devices |
| Touch Screen Support | Up to 3 TS(W)-1080-UC series touch screens |
| BYOD Support | HDMI and USB-C based content sharing and conferencing |
| Indicators | LED indicators for power, content input, outputs, and network activity |
| Power Consumption | 105W idle, 126W typical, 162W maximum |
| Power Input | 100–240 VAC |
| Operating Temperature | 32° to 104°F (0° to 40°C) |
| Humidity | 10% to 95% RH (non-condensing) |
| Heat Dissipation | 360–553 BTU/hr depending on load |
| Construction | Metal chassis, fan-cooled, vented design |
| Mounting Options | Freestanding or wall/tabletop mounting (optional bracket) |
| Dimensions (H x W x D) | 1.72 in x 8.67 in x 15.32 in |
| Weight | 8.06 lb (3.66 kg) |
| Compliance | FCC Class B, IC Class B, CE |
