Description
The CyberPower OL1000RTXL2UN is a high-performance online double-conversion UPS designed to protect critical IT and enterprise network equipment from power interruptions, surges, and voltage instability. Delivering pure sine wave output with zero transfer time, it ensures seamless and continuous power for sensitive devices such as servers, storage systems, VoIP installations, and edge network closets.
With ECO Mode efficiency above 94%, ENERGY STAR® qualification, and advanced Smart Battery Management, this UPS reduces energy waste while extending battery life. The unit also includes a pre-installed RMCARD205 network management card, enabling remote monitoring and configuration through web, CLI, or NMS platforms.
Built for flexibility, the OL1000RTXL2UN supports both rack-mounted (2U) and tower deployment and can expand runtime using compatible extended battery modules—making it an ideal solution for mission-critical uptime.
| Specification | Details |
|---|---|
| Brand | CyberPower |
| Model | OL1000RTXL2UN |
| SKU | OL1000RTXL2UN |
| UPS Topology | Online Double Conversion |
| Capacity | 1000 VA / 900 W |
| Output Waveform | Pure Sine Wave |
| Transfer Time | 0 ms |
| Form Factor | Rack / Tower Convertible |
| Rack Height | 2U |
| Input Voltage Range | 96–150 VAC (100% load) |
| Nominal Output Voltage | 100–125 VAC (configurable) |
| Output Outlets | 8 × NEMA 5-15R |
| Input Plug Type | NEMA 5-15P |
| Battery Type | Sealed Lead Acid |
| Battery Quantity | 3 × 12V/9Ah |
| Runtime (Half Load) | 21 minutes |
| Runtime (Full Load) | 8 minutes |
| Recharge Time | 4 hours (0–90%) |
| Extended Battery Support | Yes (BP36V60ART2U) |
| Hot-Swappable Batteries | Yes |
| Surge Protection | 1780 Joules |
| Network Protection | RJ11/RJ45 Combo (1-In / 1-Out) |
| Management Interfaces | USB, Serial, Relay, EPO, Network Card |
| Remote Management | Yes (RMCARD205 pre-installed) |
| LCD Display | Multifunction Rotatable LCD Panel |
| ECO Mode Efficiency | >94% |
| Certifications | UL1778, RoHS, ENERGY STAR® |
| Warranty | 3-Year Limited Warranty |
| Connected Equipment Guarantee | $400,000 Lifetime |
