Description
The D-Link DGS-3130-30S is a high-performance Layer 3 stackable managed switch engineered for enterprise and metro Ethernet environments that demand scalability, security, and consistent uptime. Featuring 24 SFP ports for flexible fiber connectivity, along with 2 10GBASE-T and 4 10G SFP+ uplink ports, this switch delivers high-speed aggregation and seamless network expansion.
Built to support advanced Layer 2 and Layer 3 functionalities, the DGS-3130-30S enables efficient traffic routing, enhanced multicast handling, and robust security policies across complex infrastructures. With support for physical stacking of up to 9 units and high stacking bandwidth, it simplifies network management while increasing redundancy and performance.
Designed for reliability, the switch includes advanced resiliency features such as Spanning Tree protocols, Ethernet Ring Protection Switching, and redundant power supply support. Comprehensive QoS, ACLs, and authentication mechanisms ensure optimized traffic prioritization and secure access control, making it ideal for business-critical deployments including campus networks, data aggregation layers, and service provider environments.
| Specification | Details |
|---|---|
| Switch Type | Layer 3 Stackable Managed Switch |
| Port Configuration | 24 x SFP Ports |
| Uplink Ports | 2 x 10GBASE-T, 4 x 10G SFP+ |
| Stacking Support | Physical stacking up to 9 units |
| Stacking Bandwidth | Up to 80 Gbps per device |
| Switching Capacity | 168 Gbps |
| Forwarding Rate | 125 Mpps |
| Packet Buffer | 2 MB |
| Routing Features | Static Routing, RIP/RIPng, OSPFv2/v3 |
| VLAN Support | Up to 4K VLAN groups, VLAN tagging, Q-in-Q |
| QoS Features | 8 queues per port, traffic shaping, priority scheduling |
| Security Features | ACLs, DHCP Snooping, IP-MAC-Port Binding, 802.1X |
| Multicast Support | IGMP Snooping, MLD Snooping |
| Management Interfaces | Web GUI, CLI, SNMP v1/v2c/v3 |
| USB Port | 1 x USB 2.0 Type-A |
| Console Port | RJ-45 for CLI management |
| Management Port | RJ-45 for IP management |
| Redundant Power Support | Compatible with DPS-500A / DPS-500DC |
| Power Input | 100–240 VAC, 50–60 Hz |
| Max Power Consumption | 65.01 W |
| Dimensions | 440 x 250 x 44 mm |
| Weight | 3.5 kg |
| Operating Temperature | 0°C to 50°C |
| Cooling | Smart fan system |
| Surge Protection | Built-in 6 kV protection |
