Description
The D-Link DGS-3630-52TC/SI is a high-performance Layer 3 fully managed Gigabit switch engineered for enterprise networks, service providers, and growing business infrastructures that demand scalability, resilience, and advanced traffic control. Built as part of the DGS-3630 Series, this switch delivers reliable Gigabit connectivity with integrated 10GbE uplinks, enabling seamless aggregation of bandwidth-intensive applications such as VoIP, video conferencing, and large-scale data transfers.
Designed for flexibility, the switch supports advanced Layer 2 and entry-level Layer 3 capabilities, along with robust security, QoS prioritization, and comprehensive management tools. Its stacking capability allows multiple units to operate as a single logical switch, simplifying network expansion while maintaining high availability and fault tolerance.
With enterprise-grade features including extensive VLAN support, ACL security policies, and intelligent traffic management, the DGS-3630-52TC/SI ensures optimized network performance and operational efficiency. Ideal for core, distribution, or access layer deployments, this switch provides a scalable foundation for modern, high-demand networking environments.
| Specification | Details |
|---|---|
| Switch Type | Layer 3 Fully Managed Stackable Switch |
| Port Configuration | 44 x 10/100/1000BASE-T Gigabit Ethernet Ports |
| Combo Ports | 4 x 10/100/1000BASE-T/SFP Combo Ports |
| Uplink Ports | 4 x 10 Gigabit SFP+ Ports |
| Switching Capacity | 176 Gbps |
| Packet Forwarding Rate | 130.95 Mpps |
| MAC Address Table | Up to 68K entries |
| Routing Table Capacity | IPv4: 16K entries, IPv6: 7K entries |
| Forwarding Table | IPv4: 32K entries, IPv6: 16K entries |
| Jumbo Frame Support | Up to 12 KB |
| Stacking Capability | Up to 9 units in a stack |
| Stacking Bandwidth | Up to 80 Gbps per device |
| Layer 2 Features | VLAN, STP/RSTP/MSTP, Link Aggregation, ERPS |
| Layer 3 Features | Static Routing, RIP, OSPF (with upgrades), VRRP |
| QoS Features | 8 queues per port, traffic prioritization, bandwidth control |
| Security Features | ACLs, 802.1X authentication, DHCP snooping, IP source guard |
| Management Interfaces | Web GUI, CLI, SNMP, Telnet, SSH |
| Console Ports | RJ-45 and Mini-USB |
| Management Port | Dedicated RJ-45 Ethernet management port |
| USB Port | USB 2.0 Type-A for configuration and firmware |
| Surge Protection | 6 kV protection on all Ethernet ports |
| Power Input | 100 to 240 VAC, 50/60 Hz |
| Maximum Power Consumption | 62 W |
| Cooling System | Smart fan-based cooling |
| Form Factor | 19-inch rack-mountable, 1U |
| Dimensions | 441 x 259.8 x 44 mm |
| Weight | 4.04 kg |
| Operating Temperature | -5°C to 50°C |
| Humidity Range | 10% to 95% non-condensing |
