Description
The Samsung OM75R is a 75-inch high-brightness window display designed to deliver clear, vibrant digital signage in storefronts and bright commercial environments. With 4,000 nit brightness, 4K UHD resolution, a 5,000:1 contrast ratio, and 24/7 operation support, it helps businesses present promotional content, brand messaging, and visual campaigns with strong visibility even in direct sunlight.
Built with a slim, professional design and an embedded MagicINFO Player S7 powered by Tizen, the OM75R supports efficient content playback and display management without requiring an external media player. Its IP5X rating, polarized sunglasses visibility, auto brightness control, WiFi module, and portrait or landscape installation support make it a strong choice for retail, hospitality, corporate, and public-facing signage applications.
| Specification | Details |
|---|---|
| Brand | Samsung |
| SKU | OM75R |
| Product Type | High-Brightness Window Display |
| Display Size | 75-inch class |
| Measured Screen Size | 74.5 inches |
| Resolution | 3840 x 2160 4K UHD |
| Aspect Ratio | 16:9 |
| Panel Type | 120Hz D-LED BLU |
| Brightness | 4,000 cd/m² |
| Contrast Ratio | 5,000:1 |
| Dynamic Contrast Ratio | 100,000:1 |
| Viewing Angle | 178° horizontal / 178° vertical |
| Response Time | 6 ms |
| Display Colors | 8-bit, 16.7 million colors |
| Color Gamut | 72% |
| Operation Support | Designed for 24/7 continuous operation |
| Haze | 0% |
| Inputs | 1 DisplayPort 1.2, 2 HDMI 2.0, 1 USB 2.0 |
| Outputs | HDMI 2.0 video output, stereo mini jack audio output |
| External Control | RS232C input/output, RJ45 input |
| HDCP Support | HDCP 2.2 |
| Embedded Player | MagicINFO Player S7 with SSSP 7.0 |
| Operating System | Tizen 5.0 |
| Processor | Cortex A72 1.7GHz quad-core CPU |
| Memory | 2.5GB LPDDR4 |
| Storage | 8GB internal storage |
| Wireless Connectivity | Embedded WiFi module |
| Installation Orientation | Portrait and landscape installation supported |
| Special Features | IP5X rated, polarized sunglasses viewable in any direction, auto brightness control, ambient brightness sensor, temperature sensor, RJ45 MDC, auto source switching and recovery, clock battery support |
| Power Supply | AC 100 to 240V, 50/60Hz |
| Maximum Power Consumption | 990W |
| Typical Power Consumption | 411W EU, 600W US/KOR/ETC |
| Sleep Mode Power | Less than 0.5W |
| Off Mode Power | Less than 0.5W |
| Dimensions | 1703.1 x 981.2 x 82.6 mm |
| Package Dimensions | 1890 x 1144 x 225 mm |
| Display Weight | 38 kg |
| Package Weight | 50.5 kg |
| VESA Mount | 400 x 400 mm |
| Bezel Width | 23.9 mm |
| Operating Temperature | 0°C to 30°C in direct sunlight, 0°C to 40°C without direct sunlight |
| Operating Humidity | 10% to 80% |
| Included Accessories | Quick Setup Guide, Regulatory Guide, Warranty Card, Power Cord, Remote Controller, Batteries, IR sensor, Ambient sensor |
