Description
The D-Link DXS-3130-32S is a high-performance 10G Layer 3 stackable managed switch engineered for enterprise and metro Ethernet environments that demand speed, scalability, and resilience. Designed as a powerful aggregation or access layer solution, it delivers ultra-fast connectivity with 10G and 25G uplinks, enabling seamless data flow for bandwidth-intensive applications such as cloud services, video conferencing, and large-scale data transfers.
With advanced Layer 2 and Layer 3 capabilities, the switch supports dynamic routing protocols, intelligent traffic management, and robust security features to ensure optimized network performance and protection. Its stacking capability allows multiple units to operate as a single system, simplifying management while enhancing redundancy and scalability.
Built for reliability, the DXS-3130-32S includes support for redundant power supply, rapid failover technologies, and intelligent cooling, making it ideal for mission-critical deployments where uptime and operational efficiency are essential.
| Specification | Details |
|---|---|
| Switch Type | Layer 3 Stackable Managed Switch |
| Port Configuration | 24 × 10G SFP+ ports, 4 × 10/25G SFP28 uplink ports |
| Switching Capacity | 760 Gbps |
| Forwarding Rate | 565.44 Mpps |
| Stacking Capability | Up to 9 units per stack |
| Stacking Bandwidth | Up to 200 Gbps per device |
| Routing Features | Static Routing, RIP/RIPng, OSPFv2/v3 |
| VLAN Support | Up to 4K VLANs, 802.1Q, Q-in-Q, Private VLAN |
| QoS Features | 8 queues per port, traffic shaping, DSCP/CoS prioritization |
| Multicast Support | IGMP Snooping, MLD Snooping, PIM-SM |
| Security Features | ACLs, DHCP Snooping, IP-MAC-Port Binding, ARP Inspection |
| Link Aggregation | IEEE 802.3ad, up to 32 groups |
| Redundancy Features | ERPS, STP/RSTP/MSTP, Loopback Detection |
| Management Interfaces | Web GUI, CLI, SNMP, SSH, Telnet |
| Management Port | Dedicated 10/100/1000BASE-T out-of-band port |
| USB Port | 1 × USB 2.0 for configuration and logging |
| Power Supply | Internal PSU with optional redundant power supply support |
| Cooling System | Smart fan with adaptive speed control |
| Dimensions | 440 × 250 × 44 mm |
| Weight | 3.835 kg |
| Operating Temperature | 0°C to 50°C |
| Power Consumption | Max 66.5 W |
