Description
The Eaton 124100027-002 Maintenance Bypass Panel offers seamless power transfer and maintenance support for Eaton 9355 Model 15 UPS systems. This bypass switch is engineered for 15 kW capacity and operates at 208V AC, allowing maintenance or servicing of the UPS without power disruption. It features an integrated 120 kA TVSS (Transient Voltage Surge Suppressor) to protect critical equipment from voltage spikes. Compact and durable, this unit is a reliable solution for high-availability applications.
| Specification | Details |
|---|---|
| Manufacturer | Eaton Corporation |
| Part Number | 124100027-002 |
| Product Type | Maintenance Bypass Panel |
| Compatible UPS | Eaton PW9355 Model 15 |
| Bypass Switch | Included |
| Input/Output Voltage | 208 V AC |
| Load Capacity | 15,000 VA / 15 kW |
| Surge Protection | 120 kA TVSS (Transient Voltage Surge Suppressor) |
| Height | 60 in |
| Width | 20 in |
| Depth | 5.8 in |
| Weight | 120 lb (Shipping Weight: 145 lb) |
| Product Condition | New and Factory Fresh |
| Country of Origin | United States |
