Description
Ensure uninterrupted power protection and streamlined maintenance with the Eaton 9355 Maintenance Bypass Panel (MBP), designed for 15kVA UPS systems. This 3-breaker panel includes a panelboard rated at 10kA and integrated TVSS (Transient Voltage Surge Suppression) for enhanced protection against electrical surges.
The maintenance bypass design allows safe servicing of your UPS without system downtime, while the compact and durable ANSI 61 Gray enclosure makes it ideal for mission-critical applications in data centers, hospitals, and industrial facilities.
| Specification | Details |
|---|---|
| Model Number / SKU | 124100027-009 |
| Product Type | Maintenance Bypass Panel (MBP) |
| UPS Compatibility | Eaton 9355 15kVA UPS Systems |
| Breaker Configuration | 3 Circuit Breakers |
| Input Voltage | 208Y/120 VAC |
| Main Bus Rating | 100 Amps |
| Neutral Bus Rating | 200 Amps |
| MIB / MBP / MIS Rating | 60 Amps each |
| Panelboard Interrupt Rating | 10kA |
| Surge Protection | Integrated TVSS |
| Color | ANSI 61 Gray |
| Certification | UL / C-UL Listed to UL67 Standard |
| Manufacturer | Eaton (Cutler-Hammer) |
