Description
The Eaton 93PM 100kW Tower UPS is a high-performance, three-phase power protection solution engineered for modern data centers and mission-critical environments. Designed to deliver maximum uptime and operational efficiency, this double-conversion online UPS combines advanced power conditioning with scalable architecture, ensuring continuous, clean power for sensitive equipment.
With industry-leading efficiency of up to 98.5% using Eaton’s Energy Saver System, the 93PM significantly reduces energy consumption and cooling costs while maintaining reliable protection. Its modular, space-saving design allows for seamless scalability, enabling businesses to expand capacity without disrupting operations.
Equipped with a full suite of communication cards, this UPS enables advanced remote monitoring and integration across IT and facility management systems. The intuitive LCD interface provides real-time system insights, while PredictPulse remote monitoring enhances proactive maintenance and minimizes downtime risks.
Built for flexibility, reliability, and simplified deployment, the Eaton 93PM 100kW UPS is an ideal choice for enterprises seeking robust, future-ready power infrastructure.
| Specification | Details |
|---|---|
| Brand | Eaton |
| Product Series | 93PM |
| Model | 93PM 100kW Tower UPS |
| Form Factor | Tower |
| UPS Topology | Double Conversion Online |
| Phase | Three Phase |
| Load Capacity | 100 kW |
| Input Voltage | 230 V AC |
| Output Voltage | 208 V AC / 220 V AC |
| Input Frequency | 50/60 Hz |
| Output Frequency | 50/60 Hz |
| Output Power Factor | 0.8 |
| Efficiency | Up to 98.5% (ESS), 95% in double conversion |
| Input Connection | Hardwired 4-wire |
| Output Connection | Hardwired |
| Communication Interfaces | HTTPS, SNMP, Modbus TCP/IP, Modbus RTU, BACnet IP |
| USB Port | Available |
| Emergency Power Off (EPO) | Supported |
| Display | Graphical LCD |
| DC System Voltage | 480 V DC |
| Management Features | Remote monitoring, energy tracking, load profiling, PredictPulse support |
| Application | Data Centers, Enterprise IT, Critical Infrastructure |
| Certifications | UL 1778, cULus, FCC Part 15 Class A, IEC 61000-4-5 |
| Dimensions (H x W x D) | 74" x 22" x 42" |
| Weight | 978 lbs |
| Included Features | All communication cards, 3-breaker maintenance bypass system |
| Condition | New and Factory Fresh |
