Description
The Eaton 93PM 40kW UPS delivers enterprise-grade power protection with high efficiency, scalability, and advanced monitoring capabilities, making it an ideal solution for modern data centers and mission-critical environments. Designed with N+1 redundancy, this three-phase tower UPS ensures continuous uptime and resilience against power disruptions.
With industry-leading efficiency of up to 98.5% using Energy Saver System (ESS) and up to 95% in double-conversion mode, the 93PM significantly reduces operational costs while maintaining optimal performance. Its compact footprint conserves valuable floor space, while modular scalability allows for seamless expansion as power demands grow.
Equipped with a user-friendly LCD interface and full communication card support, this system enables real-time monitoring, remote management, and integration into IT infrastructure via protocols such as SNMP, Modbus, and BACnet. The included 3-breaker maintenance bypass enhances serviceability, minimizing downtime during maintenance.
Built for flexibility, reliability, and intelligent power management, the Eaton 93PM is a future-ready UPS solution for high-density computing environments.
| Specification | Details |
|---|---|
| Brand | Eaton |
| Product Series | 93PM |
| Product Type | Double Conversion Online UPS |
| Form Factor | Tower |
| Load Capacity | 40 kW |
| Output Voltage | 208V AC, 220V AC |
| Input Voltage | 230V AC |
| Phase | Three Phase |
| Input Frequency | 50/60 Hz |
| Output Frequency | 50/60 Hz |
| Input Power Factor | 0.8 |
| Efficiency | Up to 98.5% (ESS), up to 95% (Double Conversion) |
| Redundancy | N+1 Configurable |
| Battery System Voltage | 480 V DC |
| Input Connection | Hardwired (4-wire) |
| Output Connection | Hardwired |
| Maintenance Bypass | Integrated 3 Breaker MBS |
| Display | LCD Interface |
| USB Port | Included |
| EPO Port | Included |
| Network Management | HTTPS, SNMP, Modbus TCP/IP, Modbus RTU, BACnet IP |
| Communication Cards | All communication cards included |
| Application | Data Centers, Enterprise IT, Critical Infrastructure |
| Certifications | UL 1778, cULus, FCC Part 15 Class A, IEC 61000-4-5 |
| Dimensions (H x W x D) | 74" x 22" x 42" |
| Shipping Weight | 708 lbs |
| Condition | New and Factory Fresh |
