Description
The Eaton 9PX11KPM is a high-efficiency, online double-conversion UPS delivering robust power protection for critical IT and infrastructure systems. Offering 11 kVA / 10 kW of reliable power in a compact 3U rack/tower form factor, it includes a pre-installed Gigabit Network (NETWORK-M3) card for seamless integration and remote management. With ABM® technology, hot-swappable batteries, and optional extended runtime via battery modules or supercharger, the 9PX ensures uninterrupted uptime and intelligent energy management.
| Category | Details |
|---|---|
| Model Number | 9PX11KPM |
| Power Capacity | 11 kVA / 10 kW |
| Form Factor | 3U Rack/Tower |
| Input Voltage | 208V (200–250V configurable) |
| Input Connection | Hardwired |
| Output Voltage | 208V (200–250V configurable) |
| Output Connection | Hardwired |
| Output Waveform | True sine wave |
| Topology | Online / Double-conversion |
| Efficiency | Up to 94% |
| Battery Type | Sealed lead-acid (ABM® technology) |
| Extended Battery Support | Yes, up to 5 EBMs or 12 with SC240RT supercharger |
| Communication Ports | Gigabit SNMP (NETWORK-M3), USB, RS232, relays |
| Network Card | Included (Mini-Slot, NETWORK-M3) |
| User Interface | Graphical LCD with 5-button navigation |
| Noise Level | <45 dB at 1 meter |
| BTU Rating | Online: 1920, Battery: 2900 |
| Mounting Hardware | 4-post rail kit, tower pedestals included |
| Certifications | ENERGY STAR®, cULus, NOM, CE, FCC Part 15, CISPR22 |
| Dimensions (WxDxH) | 17.3 x 27.56 x 5.1 in (3U) |
| Weight | 62 lb (approx.) |
| Operating Temp. | 0°C to 40°C (32°F to 104°F) |
| Warranty | 3-Year factory (parts, electronics, batteries) |
