Description
The Eaton 9PX3000RT is a high-performance, online double-conversion UPS that delivers 3000 VA / 2700 W of clean, continuous power. Designed for critical IT, networking, and edge applications, this 2U rack/tower UPS ensures consistent voltage regulation and reliable power protection with a true sine wave output. It features six 5-20R and one L5-30R output receptacles and includes advanced ABM battery management to extend battery service life by up to 50%. The 9PX3000RT is ENERGY STAR® certified, features a hot-swappable battery design, and is compatible with Eaton’s Intelligent Power Software Suite for comprehensive monitoring and management.
| Category | Details |
|---|---|
| Model | Eaton 9PX3000RT |
| Topology | Online/Double-conversion |
| Power Capacity | 3000 VA / 2700 W |
| Output Voltage | 120V nominal (100/110/120/125V selectable) |
| Output Receptacles | (6) NEMA 5-20R, (1) NEMA L5-30R |
| Input Voltage | 120V nominal (100/110/120/125V compatible) |
| Input Connection | NEMA L5-30P |
| Input Cord Length | 8 ft |
| Rack Size | 2U (Rack/Tower convertible) |
| Dimensions (WxDxH) | 17.3" x 23.8" x 3.4" |
| Weight | 63.1 lb |
| Battery Type | Sealed, lead-acid (hot-swappable) |
| Battery Management | ABM technology, 3-stage charging |
| Extended Battery | Supports up to 4 EBMs (9PXEBM72RT) |
| Efficiency | 91% at full load |
| Display | Graphical LCD with 5-button menu |
| Communications | USB, RS232, MiniSlot, Relay, Remote On/Off |
| Noise Level | <47 dB at 1 meter |
| Certifications | ENERGY STAR, cULus, NOM, CE, Seismic (OSHPD) |
| Warranty | 3 years electronics, 2 years battery |
| Mounting Kit | 4-post rail kit included |
| Included Software | Eaton Intelligent Power Software Suite |
