Description
The Eaton 9PXG2 3000VA UPS delivers enterprise-grade power protection for critical IT infrastructure, edge deployments, and network environments requiring consistent uptime. Built with true online double-conversion topology, it provides continuous, clean sine wave output and zero transfer time to protect sensitive equipment from power disturbances.
Designed for flexibility and scalability, this 6U rack/tower UPS features hardwired input and output connections, making it ideal for structured installations in data centers and industrial environments. The included PowerPass Distribution Module (PPDM) with maintenance bypass enables seamless servicing without interrupting connected loads.
With a unity power factor (1.0), high efficiency up to 96%, and advanced ABM+ battery management technology, the 9PXG2 maximizes performance while extending battery lifespan and reducing total cost of ownership. Integrated network management via the included NETWORK-M3 Gigabit card allows secure remote monitoring and control through Eaton’s Brightlayer Data Centers software.
| Category | Specification |
|---|---|
| Product Type | Online Double-Conversion UPS |
| Form Factor | Rack/Tower Convertible (6U) |
| Power Capacity | 3000VA / 3000W |
| Input Voltage | 200–240V (208V default) |
| Output Voltage | 120/240V |
| Input Connection | Hardwired |
| Output Connection | Hardwired |
| Output Waveform | True Sine Wave |
| Output Power Factor | 1.0 |
| Efficiency | Up to 96% at full load |
| Input Frequency Range | 50–70 Hz (60 Hz), 40–60 Hz (50 Hz) |
| Output Frequency | 50/60 Hz |
| Battery Type | Sealed Lead-Acid |
| Battery Management | ABM+ predictive battery replacement technology |
| Battery Replacement | Hot-swappable internal batteries |
| Extended Battery Support | Supports up to 12 EBMs (9PXEBM180RTG2) |
| Network Management | NETWORK-M3 Gigabit Network Card included |
| Communication Ports | Ethernet, USB, RS-232, Mini-Slot expansion |
| User Interface | Graphical LCD display with 5-button navigation |
| Noise Level | Less than 43 dB at 1 meter |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Humidity | 0–95% non-condensing |
| Altitude | Up to 3000 meters |
| BTU Rating | 415 BTU/hr (Online), 471 BTU/hr (Battery), 177 BTU/hr (High Efficiency) |
| Surge Protection | Integrated |
| Internal Bypass | Included |
| Maintenance Bypass | Included via PPDM module |
| Dimensions (HxWxD) | 10.2 x 17.3 x 27 inches |
| Weight | 203 lb |
| Certifications | cULus Listed, NOM, ENERGY STAR |
| Compliance | CISPR22 Class A, FCC Part 15 Class A |
| Included Accessories | Maintenance bypass module, network card, rack kit, tower stands, cables, quick start guide |
| Warranty | 3-year factory warranty with parts, electronics, and batteries coverage |
