Description
The Eaton 9PXG2 5000VA UPS delivers enterprise-grade power protection for critical IT infrastructure, edge deployments, and industrial applications. Designed with true online double-conversion topology, it ensures continuous, clean power with zero transfer time, protecting sensitive equipment from outages, voltage fluctuations, and harmonics.
With a unity power factor (1.0), this UPS provides maximum usable power, enabling full 5000W capacity without derating. Its hardwired input and output configuration supports high-capacity installations, while the included maintenance bypass module ensures uninterrupted uptime during servicing.
The integrated Gigabit Network Card enables secure remote monitoring and management through Eaton’s Brightlayer Data Centers suite, providing visibility and control across distributed environments. Advanced ABM+ battery management technology extends battery life and delivers predictive replacement analytics, reducing operational risk and maintenance costs.
Flexible deployment is supported with a 6U rack/tower convertible design, hot-swappable batteries, and scalability through extended battery modules. High efficiency operation (up to 96%) reduces energy consumption and cooling costs, making it ideal for modern data centers and mission-critical systems.
| Specification | Details |
|---|---|
| Product Name | Eaton 9PX UPS |
| Model | 9PX5KP2G2 |
| UPS Topology | Online Double-Conversion |
| Power Capacity | 5000VA / 5000W |
| Output Voltage | 120/240V |
| Output Waveform | True Sine Wave |
| Output Power Factor | 1.0 |
| Output Voltage Regulation | ±1% steady-state |
| Output Frequency | 50/60 Hz |
| Input Voltage | 200–240V (208V default) |
| Input Connection | Hardwired |
| Input Frequency Range | 50–70 Hz (60 Hz), 40–60 Hz (50 Hz) |
| Input Power Factor | >0.99 typical |
| Receptacles | Hardwired Output |
| Efficiency | Up to 96% at full load |
| Battery Type | Sealed Lead-Acid |
| Battery Management | ABM+ predictive battery analytics |
| Battery Features | Hot-swappable, supports EBMs |
| Extended Battery Support | Up to 12 EBMs (9PXEBM180RTG2) |
| Replacement Battery | EBP-1805 |
| Network Interface | Gigabit Network Card (NETWORK-M3 included) |
| Communication Ports | Ethernet, USB, RS-232 |
| Expansion Slots | 1 Mini-Slot |
| Software Compatibility | Brightlayer Data Centers |
| User Interface | Graphical LCD with 5-button menu, LED indicators |
| Noise Level | <43 dB at 1 meter |
| Operating Temperature | 0°C to 40°C |
| Humidity | 0–95% non-condensing |
| Altitude | Up to 3000 meters |
| BTU Rating | 655 BTU/hr (Online), 935 BTU/hr (Battery), 190 BTU/hr (High Efficiency) |
| Surge Protection | Included |
| Internal Bypass | Yes |
| Maintenance Bypass | Included via PowerPass Module |
| Form Factor | Rack/Tower Convertible |
| Rack Size | 6U |
| Dimensions (D x H x W) | 27 x 10.2 x 17.3 in |
| Weight | 203 lb |
| Included Accessories | UPS unit, PowerPass Distribution Module, Network Card, USB & RS-232 cables, rack kit, tower stands, cable gland |
| Compliance Standards | CISPR22 Class A, FCC Part 15, CE Marked |
| Certifications | cULus Listed, NOM, IEC 62040-2 Cat C2, ENERGY STAR |
| Warranty | 3-Year Factory Warranty (parts, electronics, batteries) |
