Description
The Eaton 9PX6KP2G2 9PX G2 UPS delivers exceptional power reliability, efficiency, and cybersecurity for mission-critical IT, edge computing, and data center environments. With 6000VA/5400W of true online double-conversion power, it protects sensitive equipment from blackouts, brownouts, surges, and line noise.
Equipped with ENERGY STAR®-qualified efficiency (up to 98.9%), it reduces energy and cooling costs while maintaining peak performance. The built-in NETWORK-M3 cybersecure Gigabit network card provides full remote monitoring, configuration, and firmware updates without downtime, meeting UL 2900-1 and IEC 62443-4-2 cybersecurity standards.
Exclusive ABM+ battery management technology extends battery life up to 50% and predicts replacement timelines with advanced analytics. The included 9PXPPDM2G2 PowerPass Distribution Module offers 208V–120V step-down capability and a maintenance bypass for uninterrupted service.
This 6U rack/tower UPS is ideal for enterprise, healthcare, education, and government applications where continuous uptime and energy efficiency are critical.
| Category | Specification |
|---|---|
| Model Number | 9PX6KP2G2 |
| Topology | Online Double-Conversion |
| Power Capacity | 6000 VA / 5400 W |
| Input Voltage | 200 V / 208 V / 220 V / 230 V / 240 V AC |
| Output Voltage | 120 V / 208 V (configurable) |
| Input Connection Type | Hardwire (Single-phase) |
| Output Connection Type | Hardwire |
| Power Factor | 1.0 |
| Efficiency | Up to 98.9% (AC Economy Mode) |
| Waveform | Pure Sine Wave |
| Battery Type | Valve-Regulated Lead Acid (VRLA) |
| Battery Runtime | 3 min (Full Load, 5400 W); 8.3 min (Half Load, 2700 W) |
| Battery Expansion | Supports up to 12 external modules (9PXEBM180RTG2) |
| Battery Management | ABM+ predictive analytics; 3-stage charging |
| Recharge Time | < 3 hours to 90% |
| Network Management | Pre-installed NETWORK-M3 Gigabit card (remote management, load shedding, reboots, safe shutdown) |
| Display | Color LCD with tilt and rotation |
| Mounting Options | 6U rackmount (4-post, 19 in) / Tower |
| Dimensions (H × W × D) | 10.2 × 17.3 × 27 in (259 × 439 × 686 mm) |
| Weight | 92.08 kg (203 lb) |
| Operating Temperature | 0 °C – 40 °C (32 °F – 104 °F) |
| Certifications | ENERGY STAR®, RoHS, CE, NOM, cUL, FCC Class A |
| Warranty | 3-year limited (parts, electronics, batteries) |
| Included Accessories | NETWORK-M3 card, 9PXPPDM2G2 module, USB cable, RS-232 cable, mounting hardware, tower stands |
