Description
The Eaton 9PXM12S12K-PD is a scalable, modular, online double-conversion UPS system designed for mission-critical edge, colocation, and enterprise environments. Offering 12kVA (10.8kW) of power capacity in a 21U rack/tower configuration, this TAA-compliant system includes 3x 4kVA split-phase power modules, 6x VRLA battery modules, and a NETWORK-M3 Gigabit network card for robust remote monitoring.
This system features N+1 redundancy for both logic and power, a broad range of output voltages (208–240V), and multiple outlet types—8x 5-20R, 2x L6-30R, 2x L6-20R, and 2x L14-30R. Ideal for government, finance, retail, and industrial environments, it supports battery expansion, hot-swappable components, and advanced ABM® battery management technology that extends battery life by 50%.
| Specification | Details |
|---|---|
| Model Number | 9PXM12S12K-PD |
| Topology | Online Double-Conversion (Modular, Scalable) |
| Form Factor | Rack/Tower Convertible (21U) |
| Power Capacity | 12kVA / 10.8kW (Scalable up to 20kVA) |
| Input Voltage | 208–240V (Hardwired Input, Single Phase) |
| Output Voltage Options | 110V, 120V, 127V, 208V, 220V, 240V |
| Output Receptacles | 8x 5-20R, 2x L6-30R, 2x L6-20R, 2x L14-30R |
| Included Modules | 3x 4kVA Power Modules, 6x VRLA Battery Modules |
| Battery Runtime | 6 min (full load), 14 min (half load); expandable |
| Battery Type | Hot-swappable VRLA with ABM® Technology |
| Network Management | NETWORK-M3 Gigabit Card (UL 2900-1 & IEC 62443-4-2 Certified) |
| Efficiency | 94% Online Mode / 97% Eco Mode |
| Certifications | UL, cUL, CE, FCC, RoHS, TAA Compliant |
| Environmental Range | 0°C–40°C, 5–95% RH (non-condensing) |
| Dimensions (H x W x D) | 36.5 x 17.5 x 34.5 in (927 x 445 x 889 mm) |
| Weight | 482 lbs / 218.6 kg |
| Warranty | 2-Year Limited Warranty (Extended Service Plans Available) |
