Description
The Eaton 9PXM12S12K is a modular, scalable UPS system delivering 12 kVA of double-conversion online power protection, with capacity expansion up to 20 kVA (N+1 redundancy). Designed for both rack and tower deployments, this 21U unit features hardwired input/output connections, hot-swappable power and battery modules, and advanced battery management (ABM) technology to extend battery life by up to 50%. Ideal for mission-critical environments, it supports a range of voltages, provides seamless power continuity, and is compatible with Eaton’s Intelligent Power Software Suite for remote monitoring and management.
| Specification | Details |
|---|---|
| Product Name | Eaton 9PXM UPS |
| Catalog Number | 9PXM12S12K |
| VA / Watt Rating | 12 kVA / 10.8 kW |
| Scalability | Scalable to 20 kVA (N+1) |
| Form Factor | Rack/Tower (21U) |
| Input Connection | Hardwired |
| Input Voltage Options | 110V/220V, 120V/208V, 120V/240V, 127V/220V |
| Input Power Factor | >0.99 typical |
| Input Frequency Range | 50–70 Hz (Nominal 60 Hz) |
| Output Voltage Options | 110V/220V, 120V/208V, 120V/240V, 127V/220V |
| Output Connection | Hardwired |
| Output Frequency | 60 Hz |
| Output Waveform | True sine wave |
| Output Topology | Online / Double-conversion |
| Output Power Factor | 0.9 |
| Battery Type | Hot-swappable internal batteries |
| Battery Management | ABM technology |
| Extended Battery Support | Yes (EBMs supported) |
| Expansion Slots | (2) Mini-Slot ports for optional cards |
| Software Compatibility | Eaton Intelligent Power Software Suite |
| Color | Black/Silver |
| Internal Bypass | Yes |
| Hot Swap Power Modules | Yes |
| Auto Shutdown Function | Yes |
| Compliances | TAA, FCC |
| Certifications | IEC, cULus |
| Warranty | 2-Year Factory Warranty (parts, batteries) |
| Weight | 482 lb |
| Dimensions (L x W x H) | 34.5 x 17.5 x 36.5 in |
| Operating Temperature | 0° to 40°C (32° to 104°F) |
| Relative Humidity | 5–95% non-condensing |
| Optional Cards | NETWORK-M2, MODBUS-MS, RELAY-MS |
