Description
Enhance your modular UPS system with the Eaton 9PXM 4 kVA / 3.6 kW Split-Phase Power Module. Designed for scalability, this hot-swappable module ensures uninterrupted power delivery while supporting split-phase voltages like 120/208V and 120/240V. Built with online double-conversion technology, it delivers true sine wave output for sensitive IT equipment. Featuring ABM battery management to extend service life and support for extended battery modules (EBMs), this module is ideal for mission-critical environments requiring flexibility, redundancy, and high efficiency.
| Category | Details |
|---|---|
| Product Name | Eaton 9PXM Split-Phase Power Module |
| Catalog Number | 9PXMSPPM |
| UPC | 743172091437 |
| Input Voltage | 110V/220V, 120V/208V, 120V/240V, 127V/220V |
| Input Power Factor | >0.99 typical |
| Input Frequency Range | 60 Hz: 50–70 Hz, 50 Hz: 40–60 Hz |
| Output Voltage | 120/208V |
| Output Nominal Voltage | 110V/220V, 120V/208V, 120V/240V, 127V/220V |
| Output Frequency | 60 Hz |
| Output Waveform | True sine wave |
| Output Power Factor | 0.9 |
| Topology | Online / Double-conversion |
| Battery Management | ABM 3-stage charging |
| Extended Battery Support | Yes (EBMs supported) |
| Battery Replacement | Hot-swappable |
| Internal Bypass | Yes |
| Hot Swap Capability | Yes |
| Operating Temp. Range | 0°C to 40°C (32°F to 104°F) |
| Relative Humidity | 5–95% non-condensing |
| Certifications | IEC Rated, cULus Listed |
| Compliances | TAA Compliant, FCC Compliant |
| Dimensions (L x W x H) | 8.5 in x 6 in x 23 in |
| Weight | 22.5 lb |
| Color | Black/Silver |
| Package Contents | Eaton 9PXMSPPM Power Module |
