Description
The Eaton BPM125DR is a robust Bypass Power Module (BPM) engineered for high-efficiency UPS configurations. Designed for use with Eaton 9170+, 9155, and 9PXSP 8–10 kVA UPS systems, this versatile 3U unit supports wall or rack mounting and features a hardwired input. It offers reliable split-phase power distribution through six 5-20R and three L14-30R receptacles, enabling seamless maintenance bypass without power disruption. Its durable black finish and TAA compliance make it suitable for mission-critical government and commercial applications.
| Specification | Details |
|---|---|
| Product Name | Eaton Bypass Power Module (BPM) |
| Model Number | BPM125DR |
| UPC | 743172090317 |
| Mounting | Wall-mount or Rackmount |
| Rack Height | 3U |
| Color | Black |
| Input Type | Hardwired |
| Input Phase | Split-phase (L1, L2, N, G) |
| Output Receptacles | (6) 5-20R, (3) L14-30R |
| Used With | Eaton 9170+, 9155, 9PXSP 8–10 kVA |
| Dimensions (L x W x H) | 26.5 in x 17.3 in x 5.1 in |
| Weight | 2 lb |
| TAA Compliant | Yes |
| Warranty | 2 Years |
