Description
The Eaton BPM125FR is a versatile Bypass Power Module (BPM) designed to provide seamless power continuity for UPS systems such as the Eaton 9170+, 9155, and 9PXSP 8–10kVA. Engineered for both rackmount and wall-mount configurations in a compact 3U form factor, it supports split-phase input (L1, L2, N, G) and is TAA compliant. With a hardwired input and six L6-30R output receptacles, it ensures reliable power distribution and system maintenance flexibility without interruption.
Ideal for critical IT and power infrastructure applications, this unit combines performance, ease of installation, and dependable design.
| Specification | Details |
|---|---|
| Product Name | Eaton Bypass Power Module (BPM) |
| Catalog Number | BPM125FR |
| UPC | 743172090362 |
| Mounting | Wall-mount or Rackmount (Rack Kit Included) |
| Rack Size | 3U |
| Color | Black |
| Dimensions (L x W x H) | 26.5 in x 17.3 in x 5.1 in |
| Weight | 2 lb |
| Phase (Input) | Split-phase (L1, L2, N, G) |
| Input Connection | Hardwired |
| Output Receptacles | (6) L6-30R |
| Compatible UPS Models | Eaton 9170+, 9155, 9PXSP 8–10kVA |
| Compliance | TAA Compliant |
| Warranty | 2-Year Warranty |
