Description
Ensure continuous power delivery and simplify maintenance operations with the Eaton 124100027-008 Maintenance Bypass Panel. Designed for 15kVA Eaton 9355 UPS systems, this panel features a three-breaker configuration, integrated Panelboard (PNLB), 22kA interrupt rating, and built-in TVSS (Transient Voltage Surge Suppression) for enhanced protection. Ideal for mission-critical applications, this ANSI 61 Gray cabinet ensures seamless power transfer during service or testing without disrupting connected loads.
| Specification | Details |
|---|---|
| Part Number | 124100027-008 |
| Product Type | Maintenance Bypass Panel |
| UPS Compatibility | Eaton 9355 UPS, 15kVA |
| Configuration | 3-Breaker |
| Integrated Panelboard | Yes (PNLB) |
| Interrupt Rating | 22kA |
| Surge Protection (TVSS) | Included |
| Main Bus Rating | 100 Amps |
| Neutral Bus Rating | 200 Amps |
| Breaker Ratings (MIB, MBP, MIS) | 60 Amps each |
| Input Voltage | 208Y/120 VAC |
| Color | ANSI 61 Gray |
| Enclosure | UL / C-UL Listed, Cutler Hammer |
| Mounting | Wall-mount or cabinet-integrated |
| Weight & Dimensions | See Cutler Hammer drawings |
