Description
The Eaton T2235-C2-2998 is a 2U rackmount Automatic Transfer Switch (ATS) PDU designed for high-availability power distribution in single-phase environments. With dual L5-30P inputs and (18) 5-20R outlets, this unit ensures continuous uptime by seamlessly switching power sources. Ideal for IT racks and critical infrastructure, it features a 2.88 kW maximum power capacity, 24A current rating, and a 9 ft input cord. The black, horizontally mounted unit is UL-listed and backed by a 3-year warranty.
| Category | Specification |
|---|---|
| Product Name | Eaton ATS PDU |
| Catalog Number | T2235-C2-2998 |
| UPC | 786685283937 |
| Mounting | Horizontal |
| Form Factor | 2U |
| Color | Black |
| Dimensions (LxWxH) | 15 in x 30 in x 10 in |
| Weight | 20 lb |
| Warranty | 3 years |
| Certifications | UL Listed |
| Input Connections | (2) L5-30P |
| Cord Length | 9 ft |
| Voltage | 110–125V |
| Amperage Rating | 24A |
| Power Capacity | 2.88 kW max |
| Frequency | 50–60 Hz |
| Phase | Single-phase |
| Output Outlets | (18) 5-20R |
| Circuit Breaker | 2-pole 20A |
| Outlet Control | No |
| Series | eATS |
