Description
The Eaton 124100027-004 Maintenance Bypass Panel is a high-performance power distribution accessory engineered for mission-critical UPS configurations. Designed specifically for the Eaton 9355 10–15 kVA UPS systems, this panel allows uninterrupted power delivery during UPS maintenance or replacement. It features three integrated circuit breakers, a panelboard with a 65kA interrupt rating, and built-in TVSS (Transient Voltage Surge Suppression) to protect against power anomalies. Encased in a durable ANSI 61 gray enclosure and UL 67 listed, it offers both operational flexibility and top-tier protection in a compact footprint.
| Specifications | Details |
|---|---|
| Manufacturer | Eaton Corporation |
| Part Number | 124100027-004 |
| Product Type | Maintenance Bypass Panel |
| Application | Eaton 9355 10–15 kVA UPS Systems |
| Input Voltage | 220 V AC |
| Output Voltage | 208Y/120 V AC |
| Power Rating | 15 kVA |
| Main Bus Rating | 100 Amps |
| Neutral Bus Rating | 200 Amps |
| Circuit Breakers | 3 Breaker Configuration |
| Panelboard Rating | 65 kA Interrupt Rating |
| Surge Protection | Integrated TVSS |
| Color | ANSI 61 Gray |
| Enclosure Type | UL / C-UL Listed per UL67 |
| Height | 90 in (approx.) |
| Width | 20 in |
| Depth | 5.8 in |
| Weight | Approx. 225 lb (Shipping: 300 lb) |
| Country of Origin | United States |
