Description
The Eaton Tripp Lite SMART5000RT3U SmartPro UPS delivers reliable, line-interactive power protection for enterprise servers, network systems, and telecom infrastructure. Designed with a 5000VA / 4000W output capacity, this 6U rack/tower UPS features a true sine wave output, ensuring full compatibility with sensitive electronics and mission-critical hardware.
It automatically corrects brownouts and overvoltages without switching to battery mode, preserving battery life. The unit supports dual 208V and 120V outputs simultaneously—ideal for mixed-voltage rack environments—and includes 14 outlets with 8 individually switchable load banks for optimized runtime management.
With expandable runtime, hot-swappable batteries, and optional network management cards (WEBCARDLX/SNMPWEBCARD), the SMART5000RT3U offers intelligent, scalable protection for modern IT environments. Built for performance and reliability, it’s the power safeguard professionals trust.
| Category | Specification |
|---|---|
| Model Number | SMART5000RT3U |
| Brand | Eaton (Tripp Lite Series) |
| UPS Type | Line-Interactive |
| Form Factor | 6U Rack/Tower (3U Power Module + 3U Battery Pack) |
| Output Capacity | 5000VA / 4000W |
| Output Voltage | 208V & 120V (dual simultaneous output) |
| Output Waveform | Pure Sine Wave |
| Power Factor | 0.8 |
| Input Voltage | 208V AC |
| Input Connection | NEMA L6-30P |
| Output Receptacles | (10) 5-15R, (2) 5-15/20R, (1) L14-30R, (1) L6-30R |
| Load Management | 8 individually switchable 5-15R outlets |
| Runtime (Half Load) | 38 minutes (2000W) |
| Runtime (Full Load) | 16 minutes (4000W) |
| Expandable Runtime | Yes, supports external battery packs (BP48V60RT-3U, BP48V27-2US, BP48V24-2U) |
| Battery Type | Valve-Regulated Lead-Acid (VRLA), Hot-swappable |
| Recharge Time | <4 hours (10%–90%) |
| Voltage Regulation Range | 151V–260V (automatic correction) |
| Transfer Time | 2–4 milliseconds |
| Efficiency (AC Mode) | 94% |
| Noise Level | ≤45 dBA |
| Communications Ports | (2) USB, (2) DB9 Serial |
| Network Management | Optional WEBCARDLX / SNMPWEBCARD |
| Certifications | UL 1778, CSA, NOM, FCC Class A, RoHS |
| Dimensions (H x W x D) | 5.2 × 17.5 × 25 in (each 3U module) |
| Weight | 321.6 lbs (145.9 kg total) |
| Operating Temperature | 0°–40°C (32°–104°F) |
| Warranty | 2-year standard (3 years with registration) |
| Connected Equipment Insurance | $250,000 (U.S., Canada & Puerto Rico) |
