Description
The Eaton PDU3XEVSRHWB is a 28.8kW 3-phase switched Power Distribution Unit designed for high-density data centers and network environments. Engineered to deliver intelligent power management and control, it features 30 switched outlets (24 C13, 6 C19) and a hardwired 380–415V 3-phase input for dependable load distribution.
This PDU includes a color touchscreen LCD for real-time local monitoring and integrates an LX-Platform network interface (HTML5, Java-free) for secure remote access via Ethernet, SNMP, Telnet, or SSH. Administrators can remotely monitor and control outlets individually, perform reboots, or apply lockouts to optimize uptime and reduce on-site visits.
Built for reliability and compliance, the PDU3XEVSRHWB supports IPv6, HTTPS, SMTP, SNMPv3, and Eaton’s PowerAlert Device Manager (PADM20) for centralized management. Optional EnviroSense2 modules enable environmental monitoring of temperature, humidity, and dry contacts.
Ideal for enterprise data centers, government installations, and industrial networks, this 0U vertical PDU simplifies deployment with toolless rack mounting, provides ±1% billing-grade power accuracy, and complies with TAA, RoHS, and FCC Part 15 Class A standards.
| Category | Specification |
|---|---|
| Model | Eaton PDU3XEVSRHWB |
| Type | 3-Phase Switched Rack PDU |
| Power Capacity | 28.8 kW @ 415/240V; 27.7 kW @ 400/230V; 26.3 kW @ 380/220V |
| Input Voltage | 380–415 V AC, 3-Phase, Hardwire |
| Input Amperage | 40 A (Agency de-rated continuous) |
| Output Voltage | 220–240 V AC |
| Output Receptacles | 30 total (24 × C13, 6 × C19) |
| Outlet Control | Individually switchable via network interface |
| Load Banks | 6 breakered (20 A each) |
| Display | Color touchscreen LCD (±1% billing-grade accuracy) |
| Network Interface | Built-in LX Platform, HTML5-based (no Java) |
| Supported Protocols | IPv4, IPv6, HTTP/HTTPS, SMTP, SNMPv1/v2/v3, Telnet, SSH, FTP, DHCP, NTP |
| Environmental Monitoring | Optional EnviroSense2 modules (temperature, humidity, dry contacts) |
| Network Speed | 10/100/1000 Mbps auto-sensing |
| Mounting | Vertical (0U), EIA-standard 19″ racks, toolless or bracket mount |
| Dimensions (H × W × D) | 70 × 2.17 × 2.52 in (177.8 × 5.5 × 6.4 cm) |
| Weight | 13.5 lb (6.12 kg) |
| Material | Metal |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
| Compliance | TAA, RoHS, FCC Part 15 Class A, UL 60950-1, EN 60950-1 |
| Warranty | 2-year limited warranty |
