Description
The Eaton Tripp Lite SR42UBEXP is a 42U SmartRack expandable standard-depth server rack enclosure designed for seamless integration in data center environments. Built for scalability, the SR42UBEXP serves as an expansion model for multi-cabinet bayed configurations, featuring front and rear locking doors but no side panels—ideal for hot aisle/cold aisle setups.
Engineered from cold-rolled steel with a durable powder-coated finish, this rack enclosure offers a 3500 lb (1588 kg) stationary load capacity and 2250 lb (1020 kg) rolling capacity. Adjustable vertical mounting rails accommodate equipment depths from 4 in. to 37 in., supporting all EIA-310-E compliant 19-inch equipment.
For streamlined cable management and airflow, it features vented top and open-bottom panels, toolless PDU mounting rails, and built-in grounding points. The SR42UBEXP ships fully assembled with pre-installed casters and levelers for easy deployment, and can be bayed securely with integrated tabs to create aligned rows in standard 600 mm data center layouts.
| Category | Details |
|---|---|
| Model Number | SR42UBEXP |
| Rack Height | 42U |
| Rack Type | Enclosure, Expandable (No Side Panels) |
| Device Compatibility | Servers, UPS, Network Switches, Patch Panels |
| Material | Cold-rolled steel with powder-coated finish |
| Color | Black |
| External Dimensions (H × W × D) | 78.5 × 23.63 × 43 in (199.39 × 60.02 × 109.22 cm) |
| Shipping Dimensions (H × W × D) | 85 × 26 × 45.5 in (215.9 × 66.04 × 115.57 cm) |
| Weight (Unit / Shipping) | 203 lb (92.08 kg) / 259 lb (117.48 kg) |
| Rack Depth Range | 4 – 37 in (10.16 – 93.98 cm) |
| Factory Preset Rack Depth | 27.75 in (70.5 cm) |
| Ventilation | Front-to-rear, perforated door design with 65% open area |
| Load Capacity (Stationary / Rolling) | 3500 lb (1588 kg) / 2250 lb (1020 kg) |
| Doors | Front and split rear locking, reversible, removable |
| Top Panel | Vented with toolless removable cable access ports |
| Bottom Panel | Open for cable entry |
| Mounting Rails | 4 adjustable vertical rails; square hole/cage nut compatible |
| Toolless PDU/Cable Mounting Rails | 2 rails, support up to 4 PDUs/cable managers |
| Grounding | Front and rear grounding points; quick-release ground wires |
| Mobility | Pre-installed casters (removable) and leveling feet |
| Compliance | UL 60950-1, CE, RoHS |
| Warranty | 5-year limited warranty |
