Description
The Eaton Tripp Lite SmartRack SR42UBZ4 is a robust 42U seismic-certified standard-depth rack enclosure engineered for high-density IT environments and earthquake-prone locations. Built to meet NEBS GR-63-CORE Zone 4 standards, this cabinet is ideal for securing servers, networking gear, and mission-critical equipment in data centers, factories, and other high-vibration areas.
It ships fully assembled with locking, removable doors and side panels for quick deployment. Features include massive front-to-rear ventilation (65% open perforated doors), adjustable mounting rails, tool-less accessory slots, and a grounding system. The SR42UBZ4 supports hot-aisle/cold-aisle configurations and includes M6 mounting hardware, baying brackets, and cable access points—making it a future-ready choice for secure and efficient infrastructure.
| Specification | Details |
|---|---|
| Model Number | SR42UBZ4 |
| Rack Height | 42U |
| Rack Depth | Standard |
| Unit Dimensions (HWD) | 78.5 x 23.63 x 43 in (199.39 x 60.02 x 109.22 cm) |
| Shipping Dimensions (HWD) | 78 x 25.5 x 44 in (198.12 x 64.77 x 111.76 cm) |
| Unit Weight | 353 lbs (160.12 kg) |
| Shipping Weight | 395 lbs (179.17 kg) |
| Max. Device Depth | 37 in (94 cm) |
| Min. Device Depth | 4 in (10.2 cm) |
| Weight Capacity (Stationary) | 3500 lbs (1588 kg) |
| Frame & Door Color | Black |
| Mounting Rails | 4 vertical posts, square-hole (EIA/ECA-310-E) |
| Built-in Cable Management | Yes |
| Airflow Design | 65%+ open perforated doors for front-to-rear |
| Casters | No (not pre-installed) |
| Certifications | Seismic Zone 4 (NEBS GR-63-CORE), RoHS |
| Compliance | PCI DSS, EIA/ECA-310-E |
| Included Accessories | 50x M6 Cage Nuts, 50x Screws, 4 Side Panels, 2 Baying Brackets, Grounding wires, Keys, Manual |
| Warranty | 5-Year Limited Warranty |
| UPC Code | 037332160331 |
| Device Compatibility | Servers, UPS, Network Switches, Patch Panels |
