Description
The Eaton Tripp Lite NetDirector B064-008-01-IPG is a high-performance 8-Port Cat5 KVM over IP Switch that allows secure, BIOS-level remote and local control of up to eight computers or servers simultaneously. Designed for demanding IT environments, it supports one local and one remote user access, ensuring administrators can manage critical systems from anywhere in the world.
With dual redundant power supplies, virtual media support, and TAA compliance, this 1U rackmount KVM switch offers unparalleled reliability, flexibility, and compliance for government or enterprise-grade operations. The device supports both USB and PS/2 consoles, IPv4/IPv6 addressing, and advanced security with 256-bit AES encryption and LDAP/RADIUS/Active Directory authentication.
Ideal for data centers, manufacturing control, and remote management environments, the B064-008-01-IPG combines robust performance, secure connectivity, and energy-efficient operation to keep your network running seamlessly 24/7.
| Category | Specification |
|---|---|
| Brand / Series | Eaton Tripp Lite NetDirector |
| Model Number | B064-008-01-IPG |
| Form Factor | 1U Rackmount |
| Type | 8-Port Cat5 KVM over IP Switch |
| Users Supported | Up to 2 (1 local, 1 remote) |
| Ports | 8 × RJ45 (server ports), 3 × USB-A (front), 2 × 3.5mm audio, 1 × USB mini-B, 2 × C14 power inlets |
| Supported Interfaces | USB, PS/2, VGA |
| Video Resolution | Up to 1920 × 1200 @ 60 Hz, 24-bit color |
| Network Compatibility | 10/100/1000 Mbps |
| Cascadable | Yes |
| Redundant Power Inputs | Dual IEC-320 C14 |
| Virtual Media Support | Yes (via USB 2.0 ports) |
| Authentication Protocols | LDAP, LDAPS, RADIUS, Active Directory |
| Encryption Standards | 1024-bit RSA, 256-bit AES, 128-bit SSL, FIPS 140-2 Level 1 |
| IP Support | IPv4, IPv6 Link Local, IPv6 Stateless Autoconfiguration |
| Management Interface | GUI, OSD, Pushbutton, Hotkey |
| Autoscan | Yes, user-definable (1–255s, default 5s) |
| Compatibility | All major operating systems and web browsers (IE, Firefox, Safari, Chrome, etc.) |
| Environmental | Operating: 0°C–40°C; Storage: -20°C–60°C; Humidity: 0–80% RH non-condensing |
| Construction | Metal |
| Color | Black |
| Dimensions (H×W×D) | 1.72 × 17.66 × 10.42 in |
| Weight | 7.75 lbs (3.52 kg) |
| Compliance | RoHS, REACH, FCC, TAA |
| Warranty | 3-Year Limited Warranty |
